IP VIDEO PHONE Waterproof Emergency Telephone KNZD-60

Product Application

As Public telephone for indoor or outdoor, elevator phone, Taxi or bus stands or station, Highway call box. Railway, metro, ATM machines side, Tunnel, Port, Dock, Mines, Generation facilities….

A good ideal telephone for use in wet or corrosive atmospheres

Main Features

KEY FEATURES

Broadcom professional VoIP and video chipsets

Android OS

SIP supports 5 SIP servers

7" digital TFT-LCD of 800 x 480 pixels with

VoIP/PSTN dual modules support

Visual angle adjustable display screen

Rotatable CMOS sensor camera with 2Mega pixels

Video resolutions of QCIF,CIF,4CIF,DCIF

Video codec of H.263,H.264,VC-1,MPEG4

Image format of JPEG,PNG,GIF,BMP

Video media format of mp4,3gp,flv,mkv,avi, wmv

Support Phonebook 2000 records

XML phone book, VCARD and CSV standard contact to import/export

Photo Frame/Internet Radio/Media player/Web browser

Android Application Market

TR069/IMS

2xLAN, PoE, PSTN, USB

Specification:

Main technical indexes:

1. Applicable for various types of SPC exchange and dispatching exchange system with feeding voltage of 48-69V.

2. Ambient temperature: -30 ~ +60 degreeRelative humidity: 10%~95%Atmospheric pressure: 86~106Kpa Circumstance noise: less than 60dB(A)

3. Sound level of ringing: over 70dB(A).

4. Standard frequency: low frequency group: 697. 770. 852. 941Hz,

high frequency group: 1209, 1336, 1477Hz, frequency deviation: -1.5%~+1.5%

If service line is a 3Km signal-level:

Standard frequency: low frequency group: -12dB~-6dB, high frequency group: -10dB~-4dB, level difference between low and high frequency of compound signal: 1dB~3dB, the total distortion caused by intermodulation of harmonic wave is lower than the basic level by at least 20dB.

5. Call transmission index: (5KM)SLR<12, RLR<-1, STMR>10, output impedance is 600 Ohm.

6. Super strong function is available for dialing 12 groups of numbers stored in the memory (maximum length of each number is16 digits)

Machine Parts

Robust aluminium alloy die-cast body
PCB Board
Dial pad

keypad

Applications

As Public telephone for indoor or outdoor, elevator phone, Taxi or bus stands or station, Highway call box. Railway, metro, ATM machines side, Tunnel, Port, Dock, Mines, Generation facilities….

A good ideal telephone for use in wet or corrosive atmospheres
