Hyundai Wing Body Truck (20-30 TON)

HYUNDAI truck produced in China since end of 2014, the engine is HYUNDAI POWERTEC made in Korea, engine horse power is from 360hp to 520hp, engine displace from Euro III to Euro IV, transmission is HYUNDAI DYMOS  made in Korea 12 to 16 speeds, stable quality in the world.

New HYUNDAI wing body truck model with most competitive price from China:

HYUNDAI BRAND 6X4 WING BODY TRUCK SPECIFICATION LIST

Cabin: High roof, Luxury , 2 seats+2 bed

Wheelbase: 4350+1350MM & 4700+1350MM &  5700+1350MM

Wing Body size can be designed according to user's requirement.

Total 3 Key Engine model for choice:

1. YC6MK340:340PS(250 KW),Euro IV emission,torque 1500 N.m,displacement 10.338L,Electronic
    control common rail

2. HYUNDAI POWERTEC D6CF36E4,360PS(265 KW),Euro IV emission,torque 1600 N.m,displacement
    12.742L,Electronic

     control unit nozzle

3.  HYUNDAI POWERTEC D6CF41E4:410PS(302 KW),Euro IV emission,torque 1800 N.m,displacement
    12.742L,Electronic control unit nozzle

Total 3 Gearbox model fixed to above 3 engine model accordingly:

1.  For 340PS(250 KW),9JSD150TA-B,FULLER,1500 N.m,overdrive speed with synchronizer,manual,9 forward 1 reverse

2.  For 360PS(265 KW),HYUNDAI T180S12 manual,12 forward 2 reverse,2000 N.m

3.  For 410PS(302 KW),HYUNDAI T230S12,manual,12 forward 2 reverse,2300 N.m

Driving Axle:  HYUNDAI R178HT,16T loading capacity/set, with speed ratio 4.111,3.667,4.111,4.444, 4.875 for option

Tire:  315/80R22.5-18PR tubless tire for standard,12.00R20-18R & 295/80 R 22.5 for option
