CHINA HEAVY LIFT - Nicolas MDED Model Modular Trailer

CHINA HEAVY LIFT  -  Nicolas MDED Model Modular Trailer

/products/modular-trailers

Manufacture Nicolas MDED model modular trailer, up to 34 ton axle load, 600mm suspension stroke, hydro-mechanic all-wheel steering, high flexural strength frame

Net payload capacity 22500 kg/axle line @18km/h

Dead weight 3500 kg/axle line

Max.gross capacity 34000 kg/axle line @0.5km/h

Tire quantity 8 tires / axle line

Width of Platform 2990 mm

Platform height 1080(+290)(-310) mm. Total suspension stroke 600 mm

Platform min.height 770 mm

Wheelbase 1550 mm

Trend 1820 / 735 mm

Tire specification 215/75 R17.5

Rim specification 6.00 - 17.5 (10 holes)

Approach / Departure angle 20° / 26°

Steering mechanism All Wheels steering by Hydraulic or Manual Control

Suspension Hydraulic Suspension

Support mode of platform 3 and 4 points

Brake system Dual pipeline control. Dual shoe brake and spring brake for all axles.

Maximum steering angle 55°

CHINA HEAVY LIFT  -  Nicolas MDED Model Modular Trailer

/products/modular-trailers

CHINAHEAVYLIFT is the Leading Manufacturer of Heavy Lift & Transport Equipment in China. Modular Trailer (Hydraulic Multi Axle), SPMT (Self Propelled Modular Transporters), Semi Trailer, etc. Manufacturing different type trailers can be Fully Combined with the Original Goldhofer THP/SL, Nicolas MEDE, Scheuerle Inter-Combi, Cometto. Main clients are located in over 50 countries, more than 8,000 axle lines Modular Trailer and 600 axle lines SPMT are in use around the world, including EU, US and CN region. And we adopt all Main Components from Germany to ensure the quality. Feel free to contact and looking forward to your visiting factory. CHINA HEAVY LIFT  -  Nicolas MDED Model Modular Trailer
