Whenever reliability, safety  and economic is needed, there is a solution:

Modular Trailers(Multi Hydraulic Axle Trailer) manufactured by CHINAHEAVYLIFT, for solving all the heavy-duty transport challenges in the payload range from approx. 80 tons to over 10,000 tons.

Due to the flexibility, the CHINAHEAVYLIFT Modular Trailers play an important role in most powerful heavy-duty transportation systems

worldwide, such as the in power plants, oil and gas industries, road transportation, shipyard and offshore industry, plant construction sites.

CHINAHEAVYLIFT Modular Trailers Additional components such as Goosenecks, Drawbars, Spacer, Dropdeck, Girder Bridge, Load bridges, Turn tables, etc. serve to ensure optimal adaptation to the requirements of each load and transport route.

CHINAHEAVYLIFT Modular Trailer - CHINAHEAVYLIFT Hydraulic Multi Axle Trailer - CHINA Modular Trailer

FEATURES

More than 8,000 axle lines CHINAHEAVYLIFT Modular Trailers are in use throughout the world.

Functional steering technology for All CHINAHEAVYLIFT Modular Trailers wheels. Small turning radius, 55° steering angle with hydraulic gooseneck. Both automatically and manually steering.

Extremely robust and durable vehicle construction, extremely high load bearing capacity.

The individual modules can be linked together for longitudinal and lateral in mechanical bolt-joint combination mode. CHINAHEAVYLIFT Modular Trailers

Adjustable Platform height , 300mm Hydraulic lifting suspension compensation and pendulum axle for uneven road condition. Safety valve in hydraulic circuit. CHINAHEAVYLIFT Modular Trailers

Ball Slewing Ring Bearing or Pivot Bearing. CHINAHEAVYLIFT Modular Trailers

Extensive Accessory options ensure multifunctional usability.

CHINAHEAVYLIFT Hydraulic Modular Trailer - CHINAHEAVYLIFT Hydraulic Multi Axle Trailer - CHINA Modular Trailer

Detail features of the CHINAHEAVYLIFT hydraulic modular trailer:

1). Main Frame of CHINAHEAVYLIFT Modular Trailers

　Main beam, upper and lower wing beam, cross beam, longitudinal beam, connecting pin are using special thick WH60(δb=60kg/mm2) steel plate, box-shaped structure, high strength, hard to deform, good ability for concentrated Professional materials certificate of all steel can be offered.

2). The combinations and connections of modules adopts foreign general multiunit

connect-sheets connecting, high connection strength , not easy to break, convenient connection and combination, largely increase the combination speed.

3). CHINAHEAVYLIFT Modular Trailers Suspension frame and balance arm is welding structure, high strength and delight appearance.

4). Steering of CHINAHEAVYLIFT Modular Trailers

   b. Steering rod system was optimized by computer, less steering error.

   c. Length of lateral rod is fixed, easy to exchange.

   d. Steering pad adopts multiple holes design and not need to change steering pad when combine or adding module.

   e. When the axle in maximum steering angle, the angle between lateral rod and suspension is 24 degree, in this way, the force against   lateral rod is in small quantity, not easy to deformation and break with less steering resistance.

5). CHINAHEAVYLIFT Hydraulic trailer and air pipeline adopts swift joint, combination is swift.

6). CHINAHEAVYLIFT Hydraulic suspension oil cylinder is manufactured via pull-cylinder techniques, high strength, and seals parts are all using overseas famous brand.

7). Stop valves are using imported famous ball valve, quick control.

8). All stop valves, seal parts, and valve plate are using imported brands.CHINAHEAVYLIFT Modular Trailers

9). CHINAHEAVYLIFT Hydraulic suspension oil pipe line adopts dual-pipe system, ensure the safety of operation.

10). Maximum steering angle of the first wheel is 55 degree.

11).When Three (2file and half version) or four file combination, the connection parts are strengthened, to ensure the better general strength of frame. CHINAHEAVYLIFT Modular Trailers
