brake drum/disc lathe C9365,C9365A,C9335

Main Specifications(model)

C9365A

Range of Processing Diameter(brake disk) mm

180-480

Rotating Speed of Work piece          r/min

30/49/88

Max Travel of Tool                      mm

256

Overall Dimensions          mm(L x W x H)

1320 x 1200 x 920

Packing Case Dimensions     mm(L x W x H)

1220 x 1130 x 1210

N.W/G.W                                 kg

400/500

Motor Power                             kw

1.1

Main Specifications (model)

C9365

Range of Processing Diameter        mm

Brake Drum

350-650

Brake Disc

180-480

Rotating Speed of Work piece      r/min

30/49/88

Max Travel of Tool                  mm

256

Overall Dimensions      mm(L x W x H)

1750 x 800 x 815

Packing Case Dimensions mm(L x W x H)

1165 x 956 x 915

N.W/G.W                             kg

480/580

Motor Power                         kw

1.1

Main Specifications (model)

C9335

Range of Processing Diameter        mm

Brake Drum

180-350

Brake Disc

180-350

Rotating Speed of Work piece      r/min

90

Max Travel of Tool                  mm

100

Overall Dimensions      mm(L x W x H)

695 x 565 x 635

Packing Case Dimensions mm(L x W x H)

750 x 710 x 730

N.W/G.W                             kg

200/260

Motor Power                         kw

0.75
