GPON-OLT-4020 2.488Gbps Downstream and 1.244Gbps Upstream

eatures:

Single Fiber Transceiver with single mode SC receptacle ；

1490nm continuous-mode transmitter with DFB laser；

1310nm burst-mode receiver with APD-TIA ；

Single 3.3V power supply；

Reset burst-mode receiver design；

Burst mode signal detect output which is LVTTL compatible；

Burst mode received signal strength indication (RSSI) output ；

Complies with ITU-T G984.2 Class C+；

Digital diagnostic interface compliant with SFF-8472 Rev 9.4；

Compliant with RoHS；

Operating case temperature range of  0°C to +70°C

Application:

Gigabit Passive Optical Networks (G-PON) – OLT side

Description:

The  transceiver is the high performance module for single fiber by using 1490nm continuous-mode transmitter and 1310nm burst-mode receiver. It is optical line terminal(OLT) for ITU-T G984.2. The optical transceiver is compliant with the Small Form- Factor Pluggable (SFP) Multi-Source Agreement (MSA)；

The receiver also includes the function of burst mode signal detect output and fast RSSI output which is enabled by a trigger. When the burst optical power is on, the receiver outputs high level; when the burst optical power is off, the receiver outputs low level. Fast RSSI function can satisfy more severe timing demand to monitor the power from any ONU.
