Wireless Digital USB DVR Support 4 Channel Video Inputting on One Computer
1. Digital wireless receive and record A/V signal from wireless cameras
2. Up to 4 cameras, 4 channels display at the same time
3. USB 2.0 output to PC, Transmission rate up to 480Mpit/s
4. 4 Channels available to avoid possible interference, record file format AVI and play with windows media Play
5. transmission distance is 150 meter in the open air
6. Support web service, MMS service
7. support MSN messenger & Skype for long- Range live video
like a web camera, Sharp and nature image with true color
8. support windows 2000/XP/Vista/Mac
9. receiving frequency: (FHSS) 2400MHZ-2525MHZ
10.Dimensions( W*L*H): 10*2.7*1.5CM ( without antenna)
Wireless Camera
|
Image sensor |
1/5 color CMOS |
|
Picture Element |
640 (H)* 480 (V) |
|
Scanning System |
2:1 interlace |
|
Gamma Characteristic |
0.45 |
|
S/N ratio |
>= 48dB |
|
Frequency rang |
ISM 2400 MHz- 2525MHz |
|
Backlight Compensation |
Auto |
|
TX power |
15dBm |
|
Electronic Shutter |
Auto: 1/50 (1/60) to 1/ 100.000 sec |
|
Lens |
3.6mm |
|
Frame Rate |
8-10fps (VGA),25-30fps (QVGA) |
|
Power Source |
DC12V +- 10% |
|
IR Distance |
15 meter |
|
Unobstructed Effective Range |
100-150 meter |
|
Waterproof Grade |
Lp 65 |
|
Motion Detect Distance |
10 meter (Centre) |
Adaptor
|
Input Voltage |
100-240 V AC |
|
Out put voltage |
12V DC |
|
Operating Frequency |
50/60 Hz |
|
Power output |
12V * 1A |
Wireless USB receiver
|
Supply Voltage |
USB support |
|
Demodulation Type |
FM |
|
Receiving Sensitivity |
<= -81 dBm |
|
Video cmpression |
WMV |
|
Audio cmpression |
ADPCM |
|
Channel bandwidth |
1.8 -2Mhz |
|
Power Consumption |
130mA |
|
USB driver |
Win 98,2000, XP, Vista, Win7 |
|
Dimension |
10*2.7*1.5cm (except Antenna) |
|
Operationg Temperature |
-10-60C |
