DSHD Solidifying Point Constant Temperature Water Bath

A:Product  Introduction:

 DSH Solidifying Point Constant Temperature Water Bath is designed according the requirements for constant temperature water bathstipulated in the National Standard GB/T510 “Test Methods for Solidifying Point of PetroleumProducts”.

 DSH Solidifying Point Constant Temperature Water Bath is suitable for use in sample treatment in the range ofroom temperature to 60 ℃.

B:Technicalcharacteristics:

1. Table structure, newlydesigned, and it is convenient to be operated.

2. It adopts a digitaltemperature controller, so it is convenient to set temperature with hightemperature controlling accuracy.

3. You can put 7 pieces ofsolidifying point test tubes and 2 pieces of cold filter plugging point testtubes in the bath, so it can keep temperature of 9 pieces of samples constantat a time.

4. It uses a two layerscylinder, and electric stirrer, so it can keep temperature stable atcontrolling temperature.

C:Technical parameters:

1. Constant temperaturebath:

(1) Cubage: 20 L;

(2) Types: two layerscylinder;

2. Working environment:

(1) Ambient temperature: -10℃～35℃;

(2) Relative humidity: ＜85％;

3. Stirring motor:

(1) Power: 6 W;

(2) Speed: 1200 RPM;

4. Temperature controllingaccuracy: ±0.1℃;

5. Heating power: twogrades, 1000W and 650 W;

6. Power supply: AC220V±10%, 50Hz±5%;

7. Total power consumption:not more than 1800 W;

8. Measurement range: roomtemperature ～100℃;

9. Temperature sensor:Industrial platinum; scale number is Pt100
