CVD Diamond for Dressing Tools

FOB Price

Negotiable / Piece

10 Pieces(Min.Order)

Supply Ability 2000 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Place of Origin

China

Product Description

Conventional abrasive wheels wear quite rapidly and need to have their profiles and/or cutting edges renewed at intervals by truing and dressing using diamond dressers. To satisfy the dressing needs of various types of conventional grinding wheels, many different types of dressers are available on the market.
CVD diamond dresser blanks winden the choice for the grinding technologist. With excellent thermal properties, CVD diamond dresser is supplied as small durable “logs” which integrate well into traditional dresser manufacturing techniques. Its polycrystalline nature means there is no requirement for special orientations to be set, since dressing ability is unaffected by the diamond orientation in the dressing tool.
Applications
CVD diamond dresser blanks produced by our Laboratory through DC Arc Plasma Jet is suitable for all dresser types - single point, multipoint, blade, rotary, roller etc. The choice of the size of dresser is determined by the application and suitable dimensions can be recommended on request.
Tool fabrication
Our CVD diamond dresser blanks have outstanding thermal properties and very high thermal oxidation resistance. It is ideal for secure mounting when using traditional non-ferrous metal sintering. Alternatively, the CVD diamond dressers can be brazed onto a dresser body using an active braze alloy in a non-oxidizing environment.
Benefits
·High resistance to chipping and fracture
·Uniform wear over the entire length of the dresser
·Performance independent of dressing orientation
·Excellent thermal stability
·Diamond with no binder phase
Availability
Our CVD diamond dresser is supplied as rectangular logs in various lengths and square. CVD diamond dresser products with non-standard dimensions are available on request.
