Help CenterForklift
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Place of Origin
China
MODEL CPCD 30F
Load capacity kg 3000
Load center mm 500
Power type Diesel
Max.lifting speeds(with load) mm/s 400
Max.Driving speeds(with without load) km/h 18/20
Max.Towing(with without load) kN 14.5/9.8
Gradeability(with/without load) % 15/20
Lifting height mm 3000
Free lift mm 80
Tilting angles(forward-backward) 6/12
Min.turning radius mm 2450
Min.right angle aisle width mm 2110
Min.under-clearance mm 135
Dimensions Overall length mm 3790
Overall width mm 1228
Overall height(mast lowered) mm 2110
Overall height(mast extend) mm 4250
Overall height to overhead guard mm 2090
Fork overhang mm 494
Wheel base mm 1700
Tread Tyre Front tread mm 1000
Front tread mm 970
Front tread 289-15
Front tread 6.50-10
Total weight kg 4320
Fork width mm 125
Fork thickness mm 45
Backrest height mm 1195
Fork length mm 1200
Engine Engine model A490BPG
Rate power KW 37
Ratate Speed At Rate Power rpm 2650
Max.torque Nm 148
Rotate speed at max torque rpm 1800-1900
Type of power shift Clutch Tor-con(Hydraulic)
Load capacity kg 3000
Load center mm 500
Power type Diesel
Max.lifting speeds(with load) mm/s 400
Max.Driving speeds(with without load) km/h 18/20
Max.Towing(with without load) kN 14.5/9.8
Gradeability(with/without load) % 15/20
Lifting height mm 3000
Free lift mm 80
Tilting angles(forward-backward) 6/12
Min.turning radius mm 2450
Min.right angle aisle width mm 2110
Min.under-clearance mm 135
Dimensions Overall length mm 3790
Overall width mm 1228
Overall height(mast lowered) mm 2110
Overall height(mast extend) mm 4250
Overall height to overhead guard mm 2090
Fork overhang mm 494
Wheel base mm 1700
Tread Tyre Front tread mm 1000
Front tread mm 970
Front tread 289-15
Front tread 6.50-10
Total weight kg 4320
Fork width mm 125
Fork thickness mm 45
Backrest height mm 1195
Fork length mm 1200
Engine Engine model A490BPG
Rate power KW 37
Ratate Speed At Rate Power rpm 2650
Max.torque Nm 148
Rotate speed at max torque rpm 1800-1900
Type of power shift Clutch Tor-con(Hydraulic)
