Home > Security & Protection > Access Control System > Access Controller > Fp Time Attendance & Access Control
US$ 100 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
ocom
Place of Origin:
China
Model Number:
OTA710C
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Reader for Fp Access Control (Wiegand Protocol)US$ 150 - 150MOQ: 1 Piece -
OTA750 Color Fp Time Attendance & Access ControlUS$ 230 - 230MOQ: 1 Piece
-
OTA680 Proximity Time Attendance & Access ControlUS$ 100 - 100MOQ: 1 Piece
-
OAC101(Fingerprint Access Control for Single Door)US$ 110 - 110MOQ: 1 Piece
-
OTA630 Proximity Time Attendance & Access ControlUS$ 100 - 100MOQ: 1 Piece
Brand Name
ocom
Place of Origin
China
Model Number
OTA710C
| Technical Parameters |
【Color】 Silver-black (You can also choose white, red or blue. Please refer to "Images" for these four colors.)
【Fingerprint Templates】 3,000
【Transaction Storage】 80,000
【Effective Reader Area】 16mm × 16mm
【Communication Protocol】 TCP/IP, USB, USB memory, RS-485
【Identification】 Fingerprint, Password, EM card
【LCD】 128×64 blue backlight, hi-definition quality LCD screen
【FAR】 ≤ 0.0001%
【FRR】 ≤ 0.01%
【Response Time】 ≤ 1 second
【Verification Mode】 1: N, 1:1
【Anti-static Strength】 < 15kv
【Language】 Chinese, English, Spanish, Korean, Arabic, Russian, German, French, Portuguese
【Temperature & Humidity】 10°C ~ 55°C, 0%-95% (no condensation water)
【Voltage】 DC9V~12V 1.5A
【Back-up Battery】 Optional (Usually no back-up battery provided)
【Power Consumption】 < 5W
【Weight】 450g
【Dimension】 167mm×130mm×45mm
【Relay Output】 Yes
【Time Authorization】 Yes
【Record Check】 Check attendance records directly in OTA710C
| Function Parameters |
◆ Using ATMEL industrial chip, 200M dominant frequency kernel; computing speed significantly improved; double speed for fingerprint identification (the speed is less than 1 second when templates of fingerprints reach 3,000)
◆ Using USB protocol; the speed is 5~10 times than that of traditional serial communication protocol
◆ Mainstream TCP / IP design; supporting cross-network segment & cross-gateway to easily access to complex network environment
◆ No need Brightness Enhancement Film (BEF); easy to identify dry, damaged and incomplete fingerprints; still can be identified when rotating fingerprint 360 degree
◆ Ultra-low power consumption structure & watchdog timer to make it more stable
◆ Perfect access control functions with group/ time-zone/ time-period setting and remote door-open/ door-close, etc.
◆ SMS (short message) publishing to improve the efficiency of interaction
◆ Multi-language software to achieve WEB queries and multi-level management
◆ SDK provided; secondary development supported
| Backup Battery Parameters |
【Rated Parameter】 6V 1200mAh
【Charging Current】 Floating
【Operation Time】 About 3 hours
【Charge Time after Deep Discharge】 About 20 hours
Note: the service life of rechargeable battery will be gradually shortened as time goes by.
