200W LED high bay light, CREE XPER3 LED, ETL approved High quality LED high bay light, high brightness LED high bay light, 3 years warranty time LED High bay light, . Ies file available
1. Feature:
>Honored to work with CREE as light source
>50% less on weight than universal mold high bay light
>Exclusive mold involving heat sink/ driver/ reflector
>Wide voltage input and constant current design
>A transparent veil available to anti-dust and LEDs protection
>Optional beaming angle such as 60° / 30° Ensures super high illumination in lux
>Certificate: CE, RoHS, ETL coming soon
>Dimension: Dia30cm*H32cm
>Ies file of this series is available
2. Packing
Net Weight: 2.7kg/ea
Gross Weight: 5kg/ea
Package Size: 57*cm*57m*46cm/ea
3. Applications
THE LED High Bay Lights are good choice for the lighting in buildings, factory workshop, warehouse, large supermarket, stadiums etc.
| Electrical Specifications | |||
| Part No. | Led Source | Power Consumption | Avg. Luminous Flux |
| FK-IL200W-XXN-SE | High Power LED from CREE/Sumsang | 200W | 15000lm |
| Input Voltage | AC85~277V |
| Frequency Range of PSU | 50Hz~60Hz |
| Total Harmonic Distortion | ≤ 9% |
| Power Factor | > 0.95 |
| Power Efficiency | > 86% |
| Luminous Efficiency | > 77lm/W |
| Working Temperature | -40Centi deg. ~+55Centi deg. |
| Storage Temperature | -25Centi deg. ~+65Centi deg. optimum @25Centi deg. |
| IP Grade | 65 |
Photometric Specifications:
| Led Luminous Efficiency | > 90lm/W |
| Color Rendering Index | WW> 68; PW, CW> 75 |
| Color Temperature |
WW(2800K~3300K); PW(4000~5500K); CW(6000~7000K) |
Mechanical Specifications:
| Beam Angle | 15° /30°/45° /60° /100° |
| Mount/ Base type | Hanging Hook |
| Material of the lamp shell | Aluminum |
