Small Volume Integrated Fingerprint Module KO-ZA10
- 50000 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Fingerprint Module with High Strength Anti-Wear KO-ZA20
-
The Most Advanced RF-type Fingerprint Sensor KO-ZA30
-
Day & Night Camera Recorder Hunting Camera KO-HC01
-
Hidden Hunting Camera with SD card KO-HC02
-
Wireless Remote Digital Hunting Camera KO-HC04
-
Digital Wildlife Hunting Camera and Screen KO-HC03
Product Details
| Brand Name | KO | Place of Origin | China | |
| Model Number | KO-ZA10 |
Product Description
Product Description:
ZA10 is small volume integrated fingerprint module. Users can conduct secondary develop, can be embedded into a variety of end products, such as: access control, attendance, safe, car door locks.
Technical parameters:
Power supply: DC 3.6 ~ 6.0V
Working Current: 100mA (typical)
Peak Current: 150mA
Scan fingerprint image time: <0.5 second
Window size: 14 × 18mm
Compared to the way (1:1)
Search method (1: n)
Profiles: 256-byte
Template file: 512
Storage capacity: 900
Safety Level: 5 (from low to high: 1,2,3,4,5)
False Accept Rate (FAR): <0.001% (security level is 3)
False Reject Rate (FAR): <0.1% (security level is 3)
Search time: <1.0 seconds (1:1000, the mean)
PC Interface: UART (TTL logic level) or USB1.1 communication baud rate (UART): (9600 × N) bps where N = 1 ~ 12 (default value of N = 6, that is 57600bps)
Working environment: Temperature: -20 ° C to +65 ° C
Relative Humidity: 40% RH-85% RH (no condensation)
Storage circumstance: Temperature: -40 ° C to +85 ° C
Relative humidity: <85% H (without condensation)
Split: module: 28 × 19 × 8.5mm
Fingerprint sensor: 56 × 20 × 21.5mm
