Container Chassis / Skeletal Semitrailer / Semi Trailer

Gooseneck Container Chassis / Skeletal Semitrailer

==============================
Contact Person : William Zhan
Tel:86 139 6981 0865
Fax:86 532 8693 5899
Email: william.cimc@gmail.com
===============================

Specifications:
1) Dimensions and weight:
a) Nominal dimensions (L x W x H): 12,480 x 2,440 x 1,460mm
b) King pin height: 1,220mm
c) King pin setting: 760mm from rear face of front bolster
d) Max. payload: 30,000kg
e) Tare weight: 3,000kg±2%
2) Running system:
a) Suspension system: leaf spring or airbag suspension
b) Axle: various axles like BPW, York, Fuwa, with various bearings
c) Tire: various brands of bias tyres or radial tires
d) King pin: forged steel, 2" or 3.5", welded or bolt-in
e) Landing gear: 24T, 25T
3) Chassis:
a) Provides twist locks and corner locks
b) Main beam: high-tensile steel
c) Surface preparation: shot blast all steel surfaces to achieve SA2.5 or
SP-10
d) Painting: zinc-rich primer and modified urethane topcoat as customers'
choices
4) Brake system:
a) Double line air brake system with single air tank, standard connectors
on front bolster
b) Optional anti-lock brake system
5) Electrical system: standard electrical equipment
