Certification:CE/ ROHS/ ETL
Full Color Outdoor Advertising Led Displays IP65 P10 with SMD 3535
Specifications:
| Model No. | OP10M |
| Pixel Pitch | 10mm |
| Pixel Package | SMD3535 |
| LED Configuration | 1R1G1B |
| Pixel Density | 10000 Pixels/㎡ |
| Module Size | 160mm x 160mm |
| Module Resolution | 16 x16 dots |
| Suggested Cabinet Size | 960mm x 960mm x 150mm |
| Cabinet Resolution | 96 x 96 dots |
| Cabinet Material | Iron / Aluminum |
| Cabinet Weight | ＜ 45kg/㎡ |
| Brightness | 6000 nits |
| Color Temperature | 3000-12000K |
| Viewing Angle | H-120°/ V-120° |
| Driving Mode | 1/4 |
| Refresh Rate | 960-2880Hz |
| Frame Frenquency | 60Hz |
| Grey Level | 4096-16384 |
| Number of Color | 1 Billion |
| Input Maximum Power | 530 W/㎡ |
| Input Voltage | AC220±10%, AC110 ±10% |
| Input Frequency | 50-60Hz |
| External Interface | S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc |
| IP Rating | IP65 |
Description:
1. We are not producer only, but also offer the whole solution for your specific LED display project, include: control system, software, installation drawing and tech support, etc.
2. Outdoor Fixed installation cabinet: Waterproof Protection,Standard: IP65/IP54.
6. Reference installation method: wall mounted curved type single/double pillar etc.
Applications:
TV station, School, Resturant, Mall ,etc.
Our Services:
Two-year quality warranty with lifelong maintenance.
Free guarantee repair (including labor and material); free repair service during the quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.
Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support.
Spare parts: necessary spare parts are provided together with products to customers.
Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.
· Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.
Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.
Site instruction service of installation is available.
Free on-site service for hardware related issues .
