Specifications
Geomembrane Linings and Liners1.High strength good extensibility
2.Can be recycled for usage
Geomembrane Linings and Liners
Product Description
the HDPE Plastic Geomembrane is a waterproof membrane made by polyethylene (PE), After the processes of calendering, spreading and rolling you will get the product.
Product Features
HDPE waterproof roll has the advantages of low coefficient of permeability, uniform thickness, good environment stress crack resistance, good resistance to chemical corrosion,good resistance to deformation, good tolerance at different temperatures, good resistance to puncture.
Application Range
|
Landfills
|
Power
|
|
Concrete Protection
|
Liquid Containment
|
Properties |
Test Method |
Value
|
|||||||
ASTM D5199 |
0.75 mm |
1.00 mm |
1.25 mm |
1.50 mm |
2.00 mm |
2.50 mm |
3.00 mm |
||
Density(Min.) |
ASTM D1505 |
0.940g/ml
|
|||||||
Tensile properties |
ASTM D6693 |
|
|
|
|
|
|
|
|
*Yield strength KN/m |
|
11 |
15 |
18 |
22 |
29 |
37 |
44 |
|
*Break strength KN/m |
|
20 |
27 |
33 |
40 |
53 |
67 |
80 |
|
*Yield elongation |
|
12% |
|||||||
*Break elongation |
|
700% |
|||||||
Tear resistance N |
ASTM D1004 |
93 |
125 |
156 |
187 |
249 |
311 |
374 |
|
Puncture resistance N |
ASTM D4833 |
240 |
320 |
400 |
480 |
640 |
800 |
960 |
|
Stress crack resistance /h |
ASTM D5397 |
300 |
|||||||
Carbon black content |
ASTM D1603 |
2.0-3.0% |
|||||||
Carbon black dispersion |
ASTM D5596 |
1 or 2 |
|||||||
(OIT) Oxidative induction time |
ASTM D3895 |
100 |
|||||||
Low temperature impact brittle property at -70°C |
|
Pass |
|||||||
Dimensional stability /% |
|
±2 |
|||||||
