Lug-Type Butterfly Valve

Lug-Type Butterfly Valve photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Place of Origin China
Lug-Type Butterfly Valve


Applicable Standards of Lug-Type Butterfly Valve

★Butterfly Valves, API 609
★Butterfly Valves, MSS SP-67
★Fire Durable, API 607
★Steel Valve, ASME B16.34
★Face to Face, API 609
★End Flange, ASME B16.5
★End Flange, ASME B16.47
★Insection And Test, API 598

Desing Description of Lug-Type Butterfly Valve

▲Seal Structure, Soft Sealing, Multiplayer-hard Seal,
Elastic Ring Hard Seal, Soft Seal Fireproof
▲Stopper Driver
▲ISO 5211 Mounting PAD
▲Connection, Flanged Butt-welded, Wafer,
Wafer Lug-wafer
▲Operation Type, Manual, Worm Gear, Electric,
Pneumatic, Hydraulic
▲Eccentric Structure, Centered, Single Eccentric,
Double Eccentric, And Triple Eccentric.

Standard Material Specifiactions of Lug-Type Butterfly Valve

NO. Part Name ASTM Material
Carbon steel 304 Type 316Type 304LType 316LType Alloy 20
1 Body A216-WCB A315-CF8 A315-CF8M A315-CF3 A315-CF3M A315-CN7M
2 Stem A182 F6a A182-F304 A182-F316 A182-F304L A182-F316L Alloy 20
3 Disc A216-WCB A315-CF8 A315-CF8M A315-CF3 A315-CF3M A315-CN7M
4 Hinge pin A276-410 A276-304 A276-316 A276-304L A276-316 Alloy 20
5 Bolt A193-B7 A193-B8 A193-B8M A193-B8 A193-B8M Alloy 20
6 Seat ring EPDM PTFE PTFE PTFE PTFE PTFE
7 Bushing Bronze 304+PTFE 316+PTFE 304L+PTFE 316L+PTFE Alloy 20+PTFE
8 Packing Graphite PTFE PTFE PTFE PTFE PTFE
9 Yoke A216-WCB A216-WCB A216-WCB A216-WCB A216-WCB A216-WCB
