Help CenterIndustrial Horizontal Multistage Centrifugal Pump Stainless Steel For Chemical Transfer
Related Products
-
Safety Horizontal Multistage Centrifugal Pump , Hot Water Circulating PumpUS$ $207 7504 - $207 7504MOQ: 1 Piece -
Electric Multistage Water Pump , Oil Circulation Pump Horizontal Easy InstallationUS$ $208 7505 - $208 7505MOQ: 1 Unit
-
Multistage Industrial Electric Water Pump Horizontal Circulating Pumps For BoilersUS$ $209 7506 - $209 7506MOQ: 1 Piece
-
Horizontal Multistage Centrifugal Pump , Hot Oil Transfer Pump High PressureUS$ $210 7507 - $210 7507MOQ: 1 Set
-
Cast Iron Horizontal Multistage Centrifugal Pump For Clear Water SupplyUS$ $215 7512 - $215 7512MOQ: 1 Set
Certification:ISO/WSC/CE/SGS
High Head Horizontal Multistage Centrifugal Pump in Low Noise
Usage:
D pump can be used to transport clear water containing no solid particles with a temperature lower than 80 Celsius degrees or liquids with similar physical and chemical properties as clear water. It's applicable for water supply and drainage works in mines, plants and cities.
DF pump can be used to transport corrosive liquids containing no solid particles with a temperature range of-20~105 Celsius degrees. The pump's allow able inlet pressure shall be less than 0.6MPa.
DY pump can be used to transport oil and petroleum products containing no solid particles with a temperature range of -20~105Celsius degrees and a viscosity less than 120 cP.
DG horizontal single-suction multi-stage centrifugal pump can be used to transport the clear water or other liquids with similar physical and chemical properties as clear water. It's applicable for the water supply in low/middle/sub-high pressure boilers as well as for the high-pressure water supply and drainage in plants or cities. The temperature range of transported medium is-20~150 Celsius degrees; and the allow able inlet pressure shall be less than 0.6MPa.
In addition, our company can provide this pump series' multi-outlet structure and function as required by customers. The user can select the pump's material, sealing mode, structure, motor capacity and soon in a reasonable way in accordance with the transported medium's name, concentration, specific gravity and working temperature, the pump's inlet pressure and so forth.
Model Meaning:
Model Meaning:
D (DF, DY) DG 46 – 30 4
D: Multi-stage clear water centrifugal pump
DF: Multi-stage corrosion-resistance centrifugal pump
DY: Multi-stage centrifugal oil pump
DG: Multi-stage boiler feed pump
46: The flow for the design point is 46m3/h
30: The single-stage lift head for the design point is 30m
4: The stage number is 4
ent System. Our product design, production and service are provided with strict and standard control systems and our product quality is fully guaranteed.
Parameters Data:
| AOLI MODEL | Capacity | Head | Power | speed | inlet | outlet |
| (m3/h) | (m) | (Kw) | (rpm) | (mm) | (mm) | |
| D/DG12-50X9 | 12.5 | 450 | 45 | 2950 | 50 | 50 |
| D/DG12-50X10 | 12.5 | 500 | 55 | 2950 | 50 | 50 |
| D/DG12-50X11 | 12.5 | 550 | 55 | 2950 | 50 | 50 |
| D/DG12-50X12 | 12.5 | 600 | 75 | 2950 | 50 | 50 |
| D/DG25-30X2 | 25 | 60 | 11 | 2950 | 65 | 65 |
| D/DG25-30X3 | 25 | 90 | 15 | 2950 | 65 | 65 |
| D/DG25-30X4 | 25 | 120 | 18.5 | 2950 | 65 | 65 |
| D/DG25-30X5 | 25 | 150 | 22 | 2950 | 65 | 65 |
| D/DG25-30X6 | 25 | 180 | 30 | 2950 | 65 | 65 |
| D/DG25-30X7 | 25 | 210 | 30 | 2950 | 65 | 65 |
| D/DG25-30X8 | 25 | 240 | 37 | 2950 | 65 | 65 |
| D/DG25-30X9 | 25 | 270 | 37 | 2950 | 65 | 65 |
| D/DG25-30X10 | 25 | 300 | 45 | 2950 | 65 | 65 |
| D/DG25-50X2 | 25 | 100 | 22 | 2950 | 80 | 80 |
| D/DG25-50X3 | 25 | 150 | 30 | 2950 | 80 | 80 |
| D/DG25-50X4 | 25 | 200 | 30 | 2950 | 80 | 80 |
| D/DG25-50X5 | 25 | 250 | 37 | 2950 | 80 | 80 |
| D/DG25-50X6 | 25 | 300 | 45 | 2950 | 80 | 80 |
| D/DG25-5 |
