Help CenterDSE330 DSE331 DSE332 DSE333 DSE334 DSE335 DSE501K DSE520 DSE550 DSE555 DSE560
Related Products
-
DSE701 DSE702 DSE703 DSE704 DSE705 DSE710 DSE720 DSE890 DSE3210 DSE103 MKIINegotiableMOQ: 1 Set -
ComAp InteliGen NT Marine GeCon InteliGen-NT-Marine-GeCon IG-NT-MARINENegotiableMOQ: 1 Set
-
ComAp IS-NT-MARINE InteliSys NT BaseBox Marine GeCon InteliSys-NT-BaseBox-Marine-GeConNegotiableMOQ: 1 Set
-
ComAp IL-NT-AMF-25 InteliLite-NT-AMF-25 InteliLite-NT-AMF-20 IL-NT-AMF-20NegotiableMOQ: 1 Set
-
ComAp IL-NT-AMF-9 InteliLite-NT-AMF-9 IL-NT-AMF-8 InteliLite-NT-AMF-8NegotiableMOQ: 1 Set
Deep Sea Electronics PLC The Model 501K-1 is a Manual Engine Control Module, which has been designed to manually control the engine via a key switch on t front panel.The module is used to start and stop the engine, indicating fault conditions; automatically shutting down the engine and indicating the engine failure by LED giving true first up fault annunciation. Operation of the module is via a three position key switch mounted on the front panel with STOP(O), RUN(I) and START(II)positions.In the‘O’position the DC supply is removed from the module and the run relay and alarm output are de-energised.If the switch is turned to the‘I’position the module is powered up and the run relay is energised, activating the engine fuel/ignition system and the protection hold-off timer is initiated.If the switch is moved to the‘II position and held against the spring return, a positive supply is applied to the relevant output terminal and on to the starter motor.Once the engine has started the switch should be released and allowed to return to the‘I’position. Operation of any of the following alarms; Low Oil Pressure, High Engine Temperature, Auxiliary Shutdown, Overspeed (Optional), will cause the run relay to de-energise.This will remove the fuel/ignition supply from the engine and bring it to rest.The alarm output will be activated giving a positive DC output. Each alarm channel has it’s own LED indicator and once activated no further alarm conditions will be accepted.?The alarm output and relevant LED will remain active until the unit is reset by turning the switch to the‘O position.Dimensions: 72 X 72 X 118.5 (Excluding Key-switch)
Chinese Web English Web /English.html Tel 0086-0754-88739001 Mobile phone 0086-13556343315 E-Mail 13556343315@139.com QQ number49960677
Send Inquiry to This Supplier
