Double Twist Automatic Hexagonal Mesh Machine For Chemical Industry

Double Twist Automatic Hexagonal Mesh Machine For Chemical Industry

Quick Detail:

1. Mesh sizes: 60x80mm

2. twist: double twist

3. Max. netting width: 3300mm

4. Max. galvanized wire diameter: 2.8mm

5. Max PVC wire diameter: 3.8mm

Descrition:

Gabion Application

Gabion Machine widely used in oil, construction, raising, chemical industry warming piping and etc. It is also

used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside,

road, bridge and civil engineering. It is one of the best against flooding material.

The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh

sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC

coated wire is available

Specifications:

1. Mesh sizes: 60x80mm

2. twist: double twist

3. Max. netting width: 3300mm

4. Max. galvanized wire diameter: 2.8mm

5. Max PVC wire diameter: 3.8mm

6. Spindle Speed:25r/min

7. Power: 15Kw

8. Size: 7200 x 1400 x 2400mm

9. Weight: 15MT

10. Theoretic output: 165m/hr

11. Automatic stop system (option): when the coiling finished or wire broken, the machine will stop

automatically

12. Infrared ray safety protection system (option)

13. Automatic oil system

Gabion Machine Working

Gabion Machine Packing

A set of gabion machine will be loaded to one 40\' container, it is nude packing and will use wire to fix the machines in the container, make sure it is safe on passage.

Competitive Advantage:

1. JINLIDA company invented the first special equipment of double twisted wire netting making machine in

China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area

of gabion machine making for 15 years.

2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to

process, so the quality can be ensured.

3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
