Single / Double Car Industrial Elevators
- T/T L/C D/P D/A
- 7 days
You May Like
-
1 Ton Double Cage Industrial Lift High Safety and Flexible Carrying
-
Single Cage Industrial Lift For Transport Personnel , Equipment and Material
-
Durable VFD Rack And Pinion Hoists For Oil Fields And Chemical Industry
-
Safety Electric Suspended Access Platform Systems for Building Working
-
Single / Double Cage Passerger Hosit
-
OEM Custom Industrial Elevators / Cargo Lift for Construction Material and Passenger
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
Single / Double Car 2700kg Capacity Industrial elevators CH Series with Mast Hot-dip Galvanized
Quick Detail:
|
Name |
Other Name |
Brand Name |
Control |
|
Industrial elevators |
Industrial elevators CH 2700/2700 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
2700kg/2700kg |
Certificate |
CE |
Description:
Industrial elevators CH 2700/2700 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial elevators has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
Applications:
CH serialization of products Industrial elevators is a Rack and Pinion EL. Industrial elevators widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications
Standard technical datas of double cars:
|
Parameter |
CH1000/1000 |
CH1600/1600 |
CH2000/2000 |
CH2700/2700 |
CH3200/3200 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Car inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
SAJ30-1.2 |
