Certification:PED
CE Low fouling Stainless Steel Tube Heat Exchanger for Swimming pools, spas heating
We produce the following products for solar, boiler or heat pump heating system
Stainless steel pool heat exchangers Titanium pool heat exchangers Sidearm heat exchangers Stainless steel electric pool heat exchangers Titanium electric pool heat exchangersFeatures of Boiler Heat Exchangers:
They are built by high heat transfer efficiency tubes, spiral twisted tubes, and smooth shell. The design produced more heat transfer efficiency, high velocities, low pressure drop and low fouling inside of the unit. It makes our heat exchangers a very reliable, efficient and cost effective way to transfer heat indirectly between any solar water heater and floor loops,besides other applications.
Fully Stainless Steel construction, they are good at sanitary water, drinking water, food process and medical process heating or cooling.
Advantages of Floor Heating Heat Exchanger:
High heating efficiency
Big flow volume with low pressure drop
Low fouling
Material: All stainless steel
Max design temperature:208°C
Max. working pressure:3.0MPa
Heat Exchangers Performance of Floor Heating Heat Exchangers:
|
Model No. |
Normal Capacity |
Heat transfer area |
||
|
kW |
Kbtu/hr |
m2 |
Ft2 |
|
|
SP-55 |
16 |
55 |
0.15 |
1.636 |
|
SP-85 |
25 |
85 |
0.25 |
2.702 |
|
SP-155 |
45 |
155 |
0.33 |
3.552 |
|
SP-210 |
61 |
210 |
0.44 |
4.769 |
|
SP-300 |
88 |
300 |
0.64 |
6.889 |
|
SP-360 |
105 |
360 |
0.85 |
9.128 |
|
SP-600 |
175 |
600 |
1.55 |
16.695 |
|
SP-1200 |
352 |
1200 |
2.01 |
21.582 |
|
SP-2400 |
704 |
2400 |
4.47 |
48.116 |
|
SP-3000 |
880 |
3000 |
5.30 |
57.051 |
|
SP-3600 |
1056 |
3600 |
6.42 |
69.107 |
|
SP-4500 |
1320 |
4500 |
8.46 |
91.066 |
Floor heating area from 40 square meter to 1500 square meter
Typical residential application:
In-floor heating
Swimming pools, spas heating
Driveway snowmelts
Typical industrial application:
Oil cooler
Transmission and engine cooler
Boiler sample cooler
Waste water heat recovery
