Help CenterSuperxon ONU Stick EPON Transceiver 1.25Gb/s For I-temp / SFP Optical Module
Related Products
-
ONU BIDI SFF Pigtail Optical Transceiver CML Logic Level Data Output InterfaceNegotiableMOQ: 1 Piece -
DDM EPON Transceiver SOEB4366-PSGB , Optical Transceiver ModuleNegotiableMOQ: 1 Piece
-
1490nm Continuous Mode ONU EPON Transceiver 10Km , SFF ModuleNegotiableMOQ: 1 Kilogram
-
1310nmTX / 1490nmRX Without MAC EPON Transceiver For Gigabit EthernetNegotiableMOQ: 1
-
Full Compatible CWDM Optical Transceiver HCWDM 6WL SMF 3.072Gbs 20KmNegotiableMOQ: 1 Piece
Certification:TUV/ FCC/ UL/ROHS/FDA
Specifications:
|
P/N |
SOEB3466-PS(I)GM |
|
Data rate: |
1.25Gb/s |
|
Distance |
PX20+ |
|
Wavelength |
1310nm T/1490nm R |
|
Transmitter |
FP |
|
Receiver |
PIN |
|
DDM |
Yes |
|
Connector |
SC |
|
Operating Temperature |
-40~85℃ |
|
Voltage Supply |
3.3V |
|
Brand |
Superxon |
|
Certification |
TUV/FCC/UL/ROHS/ FDA/CDRH |
Single fiber bi-directional data links symmetric 1.25Gbps EPON ONU application with EPON MAC function.
SC/UPC receptacle SFP with EPON ONU MAC inside, “Plug-and-play” via auto-discovery and configuration
1310nm FP burst mode transmitter, 1490nm PIN-TIA continuous mode receiver
0 to 70°C operating case temperature for SOEB3466-PSGM, C-Temp;
-40 to 85°C operating case temperature for SOEB3466-PSIGM, I -Temp;
Single 3.3V power supply
Digital diagnostic monitor interface compatible with SFF-8472
SFP MSA compliance
Low EMI and excellent ESD protection
Class I laser safety standard IEC-60825 compliant
RoHS-6 compliance
APPLICATIONS
Ethernet Passive Optical Networks(EPON)
SOEB3466-PSGM / SOEB3466-PSIGM is an MSA-compliant SFP that incorporates not just the optics for an ONU, but all of the electronics need as well. It is a “PON on a Stick” that an entire FTTH ONU in a slightly oversized SFP. It can be plugged into networking equipment. Allowing the data interfaces on a switch, router, PBX, etc. to be customized for different fiber environments and distance requirements
STANDARDS
Complies with SFP Multi-Source Agreement (MSA) SFF-8074i
Complies with IEEE 802.3ah-2004 1000BASE-PX20 EPON ONU
Highly flexible 802.1Q VALN support
802.1p/q support
Complies with SFF 8472
Complies with FCC 47 CFR Part 15, Class B
Complies with FDA 21 CFR 1040.10 and 1040.11
Competitive Advantage:
1 Competitive pricing
2.OEM/ODM Customized label
3 Keep stock , Fast delivery
4 Excellent quality with 2 years warranty
