Certification:CE,ROHS
high power SMD3528 2400mm LED tube T8 for supermarket , aluminum & PC
Quick Detail:
1. Size:D26*2400mm
2. Power:27W
3. LED quantity(pcs):576
4. LM:4752
5. power- supply efficiency :85%-87%
6. PF value: 0.97 above
7. LED angle: 120
8. Color temp:2800-6500K
9. 3 years warranty
Description:
Size: D26*2400mm
LED quantity(pcs): 576
power- supply efficiency : 85%-87%
PF value: 0.97 above
LED angle: 120
color temp: 2800-6500K
cover type: transparant and frosted
lumen LM(per 6000k): 4752
warranty: 3 years
life span: 50000H
work Temp: -30-45℃
How to install the led tube:
1.if you just replacement the traditional fluorescent led tube but use the previous light fixture, just need
knock down the fluorescent tube and remove the starter when you install the led tube.
2.if you install the light fixture and led tube for the new building, just need install the led light fixture and
then install the led tube directly or you can install the integrated led tube directly.
T8 LED tube Specification:
| Type | 2.4m(8feet) |
| Size | D26*2400mm |
| Led type | SMD3528 |
| Led quantity | 576 |
| Voltage | 85-277 |
| PF | 0.97 |
| Power | 36W |
| Ra | 70-80 |
| Led brand | Epistar |
| Warranty | 3 years |
Our product contrast with the ordinary tube :
Competitive advantages:
1. Al shell:
high quality aluminum Alloy ,safe and durable, sophisticated technology thermal conductivity is strong.
2. lamp base:
high quality PC material, good flam retardant performance, anti-aging do not change color, effectively
prevent oxidation of the electronic shock.
3. lamp shade:
Delicate and high quality PC lampshade, light transmittance as high as
98%, refraction light even high degree of safety service life is long.
4. lamp bead:
led super bright light bead, avirulent environmental protection, high conversion rate, lamp bead uniform
distribution the heat better.
Package detail:
| Carton size(mm) | pcs/carton | volume weight(kg) | Gross weight{KG) |
| 980*240*240 | 25 | 29.0 | 27.5 |
Applications:
This led tube has the widely use:
the most important use for the commercial lighting, just as the office, factory shop, parking, it will supply us
the same power but just use the one third of the traditional fluorescent tube, so it can help us save the
power for the commercial environment,
1. Office use:
2. factory shop:
Certification:
FAQ:
Q: Nearly all LED tube T8 are the same exterior,how to tell quality?
A: Price and exterior.
Though LED lighting products are with same or similar exterior,due to raw material cost difference is big,poor quality are all poor housing exterior with short FINs and light weight.So prices are also low.
Besides,the driver exterior is also low-end with poor IC,MOS and capacitances.
Q:Does LED tube T8 really have 50,000 hours lifespan?
A:50,000 or longer lifespan is only theroy from lab test.But due to working enviroments are different from in lab,actual lifespan is only <=30,000hours.
Especially for LED high bays and LED floods,the power is very huge,and lots of heat cause LEDs junction temperature very high.And light decay will be higher than low power LED products.
Our LED tubes are in the market over 7 years,and according to feedbacks from our clients,nearly no faluire in 4-5 years.
Q:For same power,why different suppliers with different brightness?
A:Different chips,or same chip but different brightness version.The brightness will be different.But for same chip and same brightness version,the brightness will be slight difference.But please make clear the difference between LEDs and lamp fixture.
For example,18W LED tube light,LEDs brightness is 2200lm,true fixture brightness is only 1700-1900lm(even lower).but many suppliers type 2200lm in their data sheet,please
