Emergency Lighting 6.0V NICD Rechargeable Batteries 2500mAh , NICAD Cells

Delivery Time:10-15 days
Certification:UL, ISO9001:2008, ISO9001:14000,SA8000

Emergency lighting Fixture 6.0V C2500mAh NICD Rechargeable Batteries UL High Temp

Quick Detail:

1 Nominal voltage: 6.0V

2 Nominal capacity: 2500mAh

3 Approx weight: 315g

4 Standard charge: 250mA×15hours

5 Standard discharge: 500mA to 1.0V

6. Tickle charge: 135～281mA

7 Discharge cut-off voltage: 5.0V

8 Temperature range for operation: (Humidity: Max.85%)

  Standard charge: 0～+70℃

  Trickle charge: 0～+70℃

  Discharge: -20～+70℃

9 Temperature range for storage: (Humidity: Max. 85%)

  Within 1 years: -20～+25℃

  Within 6 months: -20～+30℃

  Within a months: -20～+40℃

  Within a week: -20～+50℃

10. Appearance:

  There shall be no such defect as discoloration or electrolyte leakage or zero voltage

Description:

Certificate: CE,UL,KS,IEC61951-1/2

Free of maintenance

Long storage life

4 years warranty since the delivery date of factory

High charge and discharge efficiency at high temperature

Comply with ICEL1010,EN60598-2-22 and IEC61951 emergency lighting standards

The capacity maintains around 90% of original capacity after 50 cycles

Side by side or stick or customized design always available

Applications:

Emergency lighting , Emergency fixture , outdoor lighting, public lighting, LED lighting,annunciator,solar light ,emergency lighting units (exit signs, emergency lighting fixtures, conversion kits) UPS &back-up systems ,Security devices (alarms, cable networks,)

Specifications:

MAXPOWER INDUSTRIAL CO.LTD MP-NiCd  6.0V  C2500mAh battery specification
Model	MPD-C2500mAh 6.0V
Dimension	25.5*250mm   (Diameter*Height)
Voltage	6.0V
Capacity	2500mAh
Internal Impedance	<60 mΩ
Discharge cut-off voltage	5.0V
Maximum Charge voltage	7.0V
Standard charge current	0.1C for 16 hours
Standard discharge current	0.2C
Approx Weight	315g
Working temperature	Charge:0-70 degree
Discharge:-20-70 degree
Storage temperature	minus 20 - 70 degree
High temperature capacity	2500mAh
Cycle life	500-1000 cycles

Competitive Advantage:

4 years warranty since the date of delivery from our factory

10 plus years manufacturing experience in high temperature battery

A wide range of temperature adaptation(-5~70°C)

MaxPower NICAD battery Under 55℃ condition, the battery can be charged by two different charge methods, such as using 0.05C charge 24 hours and 0.1C charge 16 hours. The capacity can reach more than 90% and the battery can be widely used in security and emergency lighting field.

Excellent lifetime at high temperature

MAXPOWER NI-CD high temperature battery can keep more than 75% capacity after 4 years under -5-55 degree temperature

MAXPOWER high temperature battery can meet ICEL1010,EN60598-2-22 and IEC61951 international standards. The high class technology of long lifetime NI-CD high temperature battery which can still keep more than 75% capacity after 6 years under -5-55 degree temperature

Communication with customers

A: What are the advantages of using rechargeable NICAD batteries?

B: Performance - NiCad batteries can be more than three times longer lasting

than alkaline batteries under h
