1 Cavity 3 Gallon Automatic PET Blow Molding Machine With Mitsubishi PLC
Quick Detail:
Hisson HB-MG90 machine is the type of two stage stretch blow molding machine, specially designed for PET 3Gallon or 5Gallon bottle blow molding. Each set of our machine includes one set of preform infrared heating oven and one set of bottle blow molding part. Our HB-MG90 is suitable for blowing bottle up to 20L.
Machine main components adopt world famous brand, e.g.:
• Controller:TECHMATION (TAIWAN),
• PLC:MITSUBISHI (Japan)
• Touching screen: Weinview(Taiwan)
• Mold clamping cylinder: Festo (Germany)
• High-pressure blowing valve: Parker (Switzerland)
• Low pressure valve: Bosch(Germany)
• Transducer: MITSUBISHI(Japan)
Specifications:
HB-MG90 BMM Technical Parameters
|
ITEM |
UNIT |
HB-MG90 |
|
Cavity |
pcs |
1 |
|
duct capacity |
L |
8 |
|
duct capacity |
L |
20 |
|
Min.inner neck diameter |
mm |
55 |
|
Max.inner neck diameter |
mm |
180 |
|
duct diameter |
mm |
300 |
|
duct height |
mm |
470 |
|
Max.mould thickness |
mm |
200-350 |
|
Mould opening stroke(Adjustable) |
mm |
350 |
|
Theoretical output |
bph |
60-90 |
|
Operating pressure |
Mpa |
0.7-0.8 |
|
Blowing pressure |
Mpa |
1-3 |
|
Heater power |
kw |
15.6 |
|
Machine weight |
kg |
1350 |
|
Heater weight |
kg |
350 |
|
Machine dimension(L*W*H) |
m |
2.3×0.85×2.2 |
|
Heater dimension(L*W*H) |
m |
2.4×0.7×1.8 |
Advantage:
1. Separation type design, small occupied space, low investment cost.
2. Running with high precision, stable and quiet.
3. Electric elements are adopted worldwide famous brand.
4. You can adjust the mechanical system according to different condition.
5. Fully controlled by computer, manual operation and auto operation are optional.
6. Heating oven can be adjusted aiming at specific condition.
7. With excellent stable-temperature-holding system
8. Adjustable revolution speed
9. Low power consumption and high safety
