Custom Automatic PET Stretch Extrusion Blow Molding Machine Equipment V75S

SPECIFICATION

V75S

Basic data

 Material

PE, PP, ….

Max container capacity

L

12

 Number of die

set

1

Output(dry Cycle)

pc/hr

650

Machine Dimension(L×W×H)

M

3.5x2.2x2.8

 Total weigh

ton

8.0

Clamping Unit

 Clamping force

KN

110

 Platen opening stroke

mm

250-600

 Platen size

mm

500x550

 Max mould size(W×H)

mm

500x450

 Mould thickness

mm

260-350

speed of clamping

mm/sec.

320

speed of opening

mm/sec.

300

Extruder unit

 Screw diameter

mm

75

 Screw L/D ratio

L/D

25

 Plasticising capacity

Kg/hr

100

Number of  heating zone

zone

4

 Extruder  heating  power

KW

46

 Extruder driving power

KW

30

Rotate speed of screw

rev / min

9-87

Drive Form

transducing speed

 Speed-down Box

Alloy steel gear

Screw barrel  material

38CrMoAlA(High quality steel)

Screw bolt head:

plating horniness alloy steel

Die head

Number of  heating zone

zone

3--5

Power of die heating

KW

6.8

Double die heads(2)

mm

240-270

Three die heads(3)

mm

110-150

Foue die head(4)

mm

80-140

Max die-1 diameter

mm
