8 Pin 4-in-1 Micro Samsung Galaxy S3 Usb Charger Cable / HTC USB Charger Cable

Delivery Time:7-10 days after payment
Certification:CE,ROHS, FCC

8 Pin 4-in-1 Micro Samsung Galaxy S3 Usb Charger Cable / HTC USB Charger Cable

Quick Detail:

Name	4 in 1 charge &sync usb cable	Brand Name	ABS-C20
Color	white,black,yellow, green,blue.Pink	Feature	USB AM to iphone4s+iphone5+mini+micro usb , TPE Materieal, With DATA+Charge Func, in each port
Place of origin	Guang dong china (mainland)	Certificate	CE,RoHS, FCC

Production Introductions:

With apple 30 pin ,apple 8 pin ,Mini,Micro connectors,it is compatible with iphone,ipod,blackberry

and most mobile phones using Micro usb jack.

 Production Description:

1, Sync data or charging

     Can be through the Dock direct or indirect.

     Connect to the iphone 5/4 s/ipod/ipod Touch/Summung  etc to computer USB port, in order to achieve

 efficient sync data transmission and the charging function.

 2, 100% brand new & high quality

 3, Wide-body wire, not knot, convenient use

4, Many colors, more fashion, more personality

Wire rod Description:

1, No.of cond:4 Conductors

2, Conductor 1

a,  Material: Enameled Copper Wire 1 UEW

b,  Construction: 0.06mm/18 strands

c,  Fillers: Nylon Silk White 250D

3, Conductor 2

a, Material: Enameled Copper Wire 1 UEW

b, Construction: 0.06mm/30 strands

c, Fillers: Nylon Silk White 250D

4, Jacket

a, Material: NON Migration TPE   Dull Surface

b, Diameter:2.0*5.5mm

c, Way of Extrusion :Solid

Construction
ITEM	DESCRIPTION
No.of Cond	4  Conductors
Conductor(1)	Material/Color	Enameled Copper Wire 1 UEW / According to the picture ( 1 , 4 )
Construction	0.06 mm / 18 strands
Fillers	Nylon Silk White  250D
Conductor(2)	Material/Color	Enameled Copper Wire 1 UEW / According to the picture ( 2 , 3 )
Construction	0.06 mm / 30 strands
Fillers	Nylon Silk White  250D
Jacket	Material/Color	NON Migration TPE  Pass ROHS/Green Dull Surface
Diameter	2.0 * 5.5mm
Way of Extrusion	Solid

DESCRIPTION:［(0.06/18+250D)*2C+(0.06/30+250D)*2C］*1F
TITLE: 2.0 * 5.5 4C TPE
NO	Conductor
1	Blue
2	Nature
3	Red
4	Green

Characterisitcs:

1, Conductor Resistance:Resistance shall not exceed 0.6 ohms/m

2, Withsand Voltage test: No Breaking (250 VAC/1min,between two wires)

3, Insulation Resistance:Shall not less than 10 Mohms·m(250 VAC/1min,between two wires)

4, NON Migration Test: N0 Trace (500g;60℃;ABS;48H)

ITEM	Condition	SPEC
Conductor Resistance	￣	Resistance shall not  exceed 0.6 ohms/m
Withstand Voltage Test	250 VAC / 1 min ,
