2.4GHz Wireless Surveillance AV Receiver Recorder

2.4GHz Wireless Surveillance AV Receiver Recorder thumbnail-1
2.4GHz Wireless Surveillance AV Receiver Recorder thumbnail-2
2.4GHz Wireless Surveillance AV Receiver Recorder photo-1
2.4GHz Wireless Surveillance AV Receiver Recorder photo-2
US$ 70 - 70 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
wsc810-706
Contact Supplier Request Quote Chat Now
HK Qiangle Technology CO., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Model Number wsc810-706

Product selling point:
>380TV lines clear picture display
>Built-in 25 IR lights for 15m night vision range
>Weather-proof design for outdoor usage
>Channel scan and channel skip for multi-camera usage
>4-channel available to avoid interference
>Built-in microphone for audio monitoring
>Min. 100m transmission distance without blocks



Parameter list:




                                       Item                                    Value
  Transmission Frequency  ISM 2,400MHz~ 2,483MHz    4CH*
  Modulation Mode   FM
  Antenna Type   Camera: Omni; Receiver: Directional
  Unobstructed Effective Range   100m(Without Block)
  Operating Temperature   -10℃~ +50℃ / +14℉~ +122℉
  Storage Temperature   -20℃ ~ +60℃ / -4℉ ~ +140℉
  Operating Humidity   85%RH
  CAMERA   Imaging Sensor   CMOS
  CMOS Total Pixels   628×582(PAL) ; 510×492(NTSC)
  Horizontal Resolution   380 TV Lines
  View Angle   55°
  Minimum Illumination   5.0 Lux / F1.2 & 0 Lux(IR ON)
  Transmission Power   80mW
  Power Supply    DC 5V 1000mA
  Consumption Current   80 mA & 200mA(IR ON)
  Dimensions (Dia.xD)    ¢57mm*67mm
   Night Vision Range   15m
  RECEIVER   Receiving Sensitivity   ≤-85dBm
  Antenna Port  50ohm SMA
  Power Supply   DC 12V 1000mA
  Consumption Current   240mA
  Vided Output level  1Vp-p@75ohm
  Audio Output level   1Vp-p@600ohm
  Dimensions (WxDxH)   100×80×25mm
