5V HDMI to Composite / S-Video Audio Convertor For Display HD CCTV Camera Quick Details Products Status: Stock Brand Name: overfly Model Number: FY1320 Place of Origin: Guangdong, China (Mainland) colour: black Packaging & Delivery
| Packaging Details: | Gross weight:233g/piece Net Weight:80g/piece 103*65*20mm/piece 50pcs/carton 60*3743CM/Carton |
|---|---|
| Delivery Detail: | 15working days |
This converter box is designed to convert HDMI to either Composite Video or S-Video.
FY-1320 HDMI to Composite/S-Video,HDMI to AV Converter
FY-1320 HDMI TO AV / HDMI to Composite. This converter box is designed to convert HDMI to either Composite Video or S-Video. It allows the devices only equipped HDMI output to be connected to CRT TV. It is mostly applied in AV equipment testing.
Features
| Input HDMI Resolution | 480p (60Hz), 576P (50Hz), 720p (50Hz / 60Hz), 1080i (50Hz / 60Hz), 1080p (50Hz / 60Hz) |
| Output Signal | Composite Video (1.0Vpp), S-Video(Y:1.0Vpp / C:0.3Vpp) |
| Output Video Systems | PAL/NTSC |
| Output Video Impedance | 75Ω |
| Power Supply | DC 5V |
| Working Temperature | -25 °C to 75°C |
| Working Humidity | 10%-60% |
| Product Dimension | 118*84*28mm (L*W*H) |
Application:
- Testing for HD products factory;
- Security monitor, display HD CCTV Camera, HD DVR on an analog TV.
- Family use. When he has a HD device, but his TV is analog.
- HDMI-interfaced laptop to anan-log TV for education, business presentation, commercial promotion, conference, exhibition, etc.
Connection Image
Interface Specification
1) S-Video output
2) CVBS Out: Composite Video output
3) L/R: Audio L output
4). L/R: Audio R output
5). HDMI input: To connect HD device sources
6). DC 5V: To connect DC 5V power supply
