Home > Consumer Electronics > Audio & Sets > Professional Audio > Speaker Box

Speaker Box

Name: Speaker Box
Brand: Naphon
SKU: 152357504
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

Naphon

Place of Origin:

China

Model Number:

F12/15

Contact Supplier Request Quote Chat Now

Naphon Music Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name Naphon

Place of Origin China

Model Number F12/15

FEATURES

F series have the fashion looks, high performance and perfect timbre effect. Adopt multi-angle birch plywood,
solid & elasticity, lead to clear and minute timbre. Flexible mounting options, aluminum alloy hanger, easier
to install and dismount. Rotatable horn design, using vertical and horizontal orientation to get the best effect.
Application in live club, unobtrusive stage monitoring, AV presentations, club install etc.

SPECIFICATION

Model	F10	F12	F15	F215	F18	F218
Type Compact	2 way passive	2 way passive multi-angled vented	2 way passive multi-angled vented	2 way passive, reflex enclosure W/dual low frequency drivers	Compact, vented sub-bass system	Dual-driver vented sub-bass system
Frequency Response	65Hz-20KHz3db	65Hz-20KHz3db	55Hz-18KHz3db	45Hz-17KHz3db	40Hz-120Hz3db	35Hz-150Hz3db
Low Frequency	56Hz (-10db)	56Hz (-10db)			55Hz (-10db)
Driver	LF:1x10”(250mm), 2.5”(63mm) HF:1x1”(25mm)	LF:1x10”(250mm), 2.5”(63mm) HF:1x1”(25mm)	LF:15”(380mm) HF:1.4”(35mm)	LF:15”(380mm)/ 3”(75mm) HF:1x1.4”(35mm)	LF:18”(460mm)	LF:2x18”(460mm)
Rated Power	300W(AES) 1200W (Peak)	300W(AES) 1200W (Peak)	400W(AES) 1600W (Peak)	800W(AES) 3200W (Peak)	500W(AES) 2000W (Peak)	1000W(AES) 4000W (Peak)
Recommended Amp	400-650W at 4ohm	400-650W at 4ohm	400-800W at 4ohm	400-1200W at 4ohm	400-1000W at 4ohm	800-2000W at 4ohm
Sensitivity	96dB	96dB	99dB	101dB	99dB	102dB
Max. SPL	119db continuous, 125db peak	119db continuous, 125db peak	123db continuous, 129db peak	128db continuous, 134db peak	124db continuous, 130db peak	130db continuous, 136db peak
Impedance	8ohm nominal	8ohm nominal	8ohm nominal	4ohm nominal	8ohm nominal	4ohm nominal
Dispersion(-6db)	90 degree H x 50 degree V	90 degree H x 50 degree V	80 degree H x 50 degree V	80 degree H x 50 degree V
Crossover	2KHz passive	2KHz passive	1.2KHz passive	1.3KHz passive	120Hz	150Hz active
Connection	2xNeutrik spoken NL4
Dimensions	44.00x40.00x59.00CM	49.00x46.00x66.00CM	58.00x55.00x80.00CM	65.00x60.00x115.00CM	65.00x68.00x78.00CM	116.00x88.00x66.00CM
Gross Weight	23.50KGS	27.50KGS	37.50KGS	73.50KGS	58.00KGS	95.50KGS
