Home > Products > Plastic Film Blowing Machine > High Speed Mini Pe Plastic Film Blowing Machine 11kw 22kw 30-50kg/h
High Speed Mini Pe Plastic Film Blowing Machine 11kw 22kw 30-50kg/h
- T/T L/C D/P D/A
- 7 days
You May Like
-
Automatic LDPE HDPE Plastic Film Blowing Machine With Double Head
-
Double Colour Striped Plastic Film Blowing Machine For Low Density Polyethylene
-
600-1200mm 11kw PE Head Blown Film Extrusion Machine For Hdpe Ldpe
-
PE Rotary Head Plastic Film Blowing Machine 11KW / 22Kw / 15kw
-
PE film Rotary Die head 3 Layer Blown Film Line 15kw 380V
-
6 Color Paper Automatic Flexographic Printing Machine With Ceramic Anilox Rollers
Product Details
Place of Origin | China | |
Model Number | SJ-45 |
Product Description
Certification:CE
Quick Detail:
CE Certificate 380V 50Hz HERO BRAND 30-50kg/h Mini Size LDPE HDPE LLDPE3 Year Warranty
Description:
Use: It applies to blow various LDPE, HDPE and LLDPE plasticfilms, widely applying to food, fruit, clothing, textile, vesttype bag and etc. Packing of civil industrial products.
Feature: Mode SJ45-50 squeezing machine is adopted rotatory die head,machine tube is adopted 38CrMoAl,having the best hardness and corrosion-resisting performance after nitrogen treatment and precision processing.
FM-600 auxiliary machine can adjust and operate freely within the range of 700mm in accordance with the technological demand of different materials, and having package board mechanism which can make vest type bag.
Rolling up device with double-drawing in and do-uble cutting ope, its power is adopted moment motor, with friction plate,it can keep suitable tension, drawing in and rolling up in good order, easy to change roll.
Specifications:
Technical Parameters:
Power |
22KW |
Assistance Machine |
0.75KW |
Heating |
11KW |
Die-Head |
Φ30-80 Choose freely mm |
Screw Diameter |
Φ45/50 Choose freely mm |
Screw L/D Ratio |
L/D 28:1 |
Screw Speed |
10-100r/min |
Max Ouput |
30-50kg/h |
Film Thickness |
0.008-0.10 mm |
Film Width |
50-600 mm |
Dimension |
2200*1900*2200MM |
Weight |
2T |
