Product Details

Place of Origin	China
Model Number	OX-SP200

Product Description

Multifunctional Solar Power

Specifications

SP250-20W solar power products designed multi-function, with light weight, small size, power, and DC to AC inverter, a high conversion efficiency, charging method, such as the characteristics of diversity; to home lighting, outdoor travel, exploration, post, office provide back-up emergency power supply; product charge by: solar panels, electricity

. Product technical specifications

Model: SP250-20W	main technical parameters
Solar panels power	20Wp
AC Intelligent Charger	support 2A and 5A
Smart Solar charge current	1.1A
Battery voltage / battery capacity	12V/17Ah
DC jack maximum output current	1.5A
DC overload protection device rated current	20 A (external chip insurance, may change)
AC Load protector rated current	1.5A (external glass tube fuses can be replaced)
Built-in fluorescent light (replaceable)	bulb two 3W
AC output voltage / frequency	220V ± 10V / 50Hz ± 2Hz
AC output voltage table	Real-time display the output AC voltage
AC output power	250W
Battery operating voltage range	10.0 15.0 Vdc
Protection	voltage limit alarm protection, overload / over-temperature protection, output short circuit protection

. Charge Notices

1. AC 2A Charger (AC charger to buy)

220V AC power in place, using the exchange of multi-functional solar charger to the rechargeable power supply;

The charger is designed to exchange for the use of rechargeable batteries, so multi-purpose power supply for your internal battery to maintain the life of a longer period of time, you can not use the AC charger in any charger other than the multi - function of power for charging, improper battery charging would seriously undermine the performance of.

2. Rechargeable solar panels

will be solar panels on outdoor, south facing, so that solar panels to absorb the full sunlight, choose shade-free location, does not allow solar panels cover the surface. Solar panels and then plug the power line charge on the front panel corresponding to "SOLAR CHARGE" in the socket;

use different power solar panels charge the batteries in the multi-function power to reach a state of time is different, the product design can be multi-functional power supply solar panels matching the peak power in the range of 10W-50W single crystal of any one or polycrystalline solar panels.

3. If you want to extend the product using the time, can be attached to an external battery, the expansion of capacity

using this product will be attached to the red folder to connect to the expansion of multi-function power of the positive battery terminal;
using this product will be attached to the black wire connected to the expansion of multi-function power of the negative battery terminal
