AC/DC Adaptor

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

YLJ-A24XXXYYYY-GS 0-21W

Output Power:

1 - 50W

Foshan Ukicra Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number YLJ-A24XXXYYYY-GS 0-21W

Output Power 1 - 50W

Input Voltage 220V

Output Voltage 6v,9v,12v,18v,24v

Output Frequency 50HZ-60HZ

Specifications

Adaptor series 0-21W,Small and light ,High performance-price ratio,Short-circuit protection for continuous output ,

Adaptor series 0-21

1, Small and light

2, High performance-price ratio

3, Short-circuit protection for continuous output

4, The protection for output over-voltage and output over-sensitivity

5, Through the relevant electromagnetic compatibility standards

Input	Input voltage 100V-240V0.5A Surge Current, Cold start 30A/230V Input Frequency 50HZ-60HZ Leakage current 0.5mA/230V
Output	Linear adjust rate ±0.5%max Temperature coefficient ±0.02%°C Starting time ≤1S(230VACIN,IO=100%) Keeping time ≥20MS(230VACIN.IO=100%)
Protection function	Overload 105%-150% Rated power Over-voltage 110%-135% Standard voltage
Insulation Intensity	Input — Output 3000VAC 1.5mA / minute
Insulation Resistance	Input — Output ≥20M 500VDC
Ripple and Sound	(mVp-p)≤1% Output voltage
Environment	Working Environment 0~45°C ,20%~90%RH Stock Environment -20~85°C 10%~90%RH
Seize	75MM45MM33MM
Weight	120G
Model	Output voltage	Output current	Power	Power	Adjust rate	Unit price (RMB / PCS)
YLJ0620A	6VDC	2000MA	12W	73%	±5%

YLJ0920A	9VDC	2000MA	18W	75%	±5%

YLJ1215A	12VDC	1500MA	18W	80%	±5%

YLJ1810A	18VDC	1000MA	18W	82%	±5%

YLJ2408A	24VDC	800MA	19.2W	85%	±5%
