F100 Mini Touch The Cash Register

Product Description

Product performance

Microsoft Windows XP operating system

CPU Intel Atom E6XX series, the main frequency optional 600 MHZ / 1.0 GHz / 1.3 GHz / 1.6 GHz;

512 KB supports hyper-threading, the second level cache;

The integrated chipset, system bus 800 MHZ frequency;

Integrated high-definition graphics, including 2 d / 3 d graphics engine, 256 MB ram, support OpenGL 1.0, DirectX9.0 c * * ES2.0, OpenVG *, support mainstream MPEG2 and MPEG4,'s VC1, WMV9, h. 264 coding of hd 1080 p video output

512 MB / 1 gb DDR2 memory

The Chip Set Intel Topcliff PCH EG20T

RTL8111D gigabit nic chip

Hard disk storage device electron is the largest 128 gb

RGB LCD screen 8.0 "TFT, resolution: 1024 x 768, screen Angle can be adjusted

Touch screen resistive, supporting the handwritten Chinese character input

Small features standard PC keyboard parts of the keyboard, a total of 28 key

Dual channel stereo audio

58 mm thermal printer, printer paper biggest diameter of 60 mm

Wireless Mini PCIe WiFi communication module is optional; The Mini PCIe 2 g / 3 g communication module is optional

RFID reading head 13.56 MHz, optional

Caller id support FSK and DTMF double system, optional

SD booth 2

SIM booth 1

One contact IC gets stuck

PSAM booth 1

Serial port 2, one is a fully functional serial interface, can be an external barcode gun, MIS - POS or display screen

USB 3, can meet the custom keyboard, standard PC keyboard, mouse, U disk, U Key

So 1, standard RJ45 socket, connect the network cable

Line 1 mouth, can be inserted into the extension telephone line

1 VGA port, the large screen display

Outside guest show power supply port 1, used to briefly show screen supply 5 v DC power supply

Cashbox pin 1

1 for electrical outlet, access to 24 v DC power supply

The battery 11.1 V, 3000 ma, three batteries, lithium polymer battery, can be in power grid power failure, to maintain the machine work more than 2 hours

The power supply 24 v, 3 a power adapter
