Nd.Yag Long Pulse Laser Varicose Veins Removal Beauty Equipment With Cooling Head PC01

Nd.Yag long pulse laser varicose veins removal beauty equipment with

cooling head  PC-01

100,000 shots

CE approval

skin rejuvenation

laser hair removal

varicose vein removal

LOGO service free of charge

Theory

This laser machine P001 adopt 1064 long pulse width, so that it can penetrate to hair follicle.

Using selective light absorption theory, laser can be preferentially absorbed by the melanin and

hemoglobin. And then heating the hair shaft and hair follicle quickly to make them necrosis for

reaching a very efficient hair removal

Specification

Long pulse laser Control system:  TFT microcomputer system

Laser type: Nd Yag laser

Wave length:   1064nm/532nm

Max energy output:    300J /cm2

Pulse width:  1ms--30ms

Spot size:   diameter 1mm--12mm

Long pulse laser conduct system: directly conduct system

Indicator light:   diode laser 650nm

Cooling system:    water cooling system

Material:   ABS material

Size:    340mm(W)x370mm(L)x580mm(H)

Voltage:   AC220V/110V   10A  50/60HZ

Treatment

1.Permanent hair reduction on all skin types

2.Skin Rejuvenation/Skin Tightening/Wrinkles

3.Vascular lesions treatment/Facial Veins /Leg Veins

4.Nail fungus treatment/ onychomycosis removal

 Advantages

1. Suitable to all skin types

2.The penetration is very deep into the skin layers, thus giving the excellent result.the powerful energy could directly

arrive and effect on hair follicle

3.  Adjustable long pulse width from 1ms-30ms,which could balance the energy intensity,greatly protect the normal skin in treatment

4.Infrared built in the handpiece thus making easier for the user to remove one hair follicle or small freckles

5.  CPC instantly plug play injection parts, fast connection and easy to install

6.High level semiconductor cooling system can greatly extend the working hours, it can work continuously for at least 7-8 hours

7.laser waveform is flat top square waveform,the output energy is very stable

Features

A. The best-wavelength laser:

 Laser hair removal must satisfy two important conditions;

For the first: laser hair follicles have been able to fully absorb the organization;

Second: the laser can effectively pass through the skin to reach the location of the hair follicle. Long-pulse laser’s wavelength is 1064nm, It is a spectrum of near-infrared region, and better absorption of melanoma at the same time to penetrate the deep dermis and subcutaneous fatty tissue, in different parts of the role and depth of the hair follicle, effectively removing any parts of the human body and depth of the hair.
As for the result of the leg veins, telangiectasia, vascular diseases such as tumors of the target tissue - oxyhemoglobin, the use of selective absorption of the target tissue, long width pulsed laser pulse width Principles, making relaxation in the thermal effect of pre-time Treatment to reach target tissue.

B. Adjustable long pulse width: It can protect the normal skin while removing different types of pigment diseases

 Best result of hair removal connect with the pulse width and thickness of hair. Coarse hair the more necessary for the role of laser longer, the long-pulse laser pulse width is from 1 ms to 30 ms, It can obtain the desired effect of hair removal, At the same time, It can effectively protect the skin from heat damage.

It can effectively penetrate the hair follicle to the site, the wavelength of the laser is around 1064nm, in the near-infrared spectral region, the absorption of melanin in the hair follicle, resulting in selective destruction, so that the hair follicle degeneration, shrinking to the role of permanent hair removal And therefore the more coarse black hair and Vietnam, its hair follicles bigger, deeper melanoma, it's more acceptable to the laser damaging effects, the better it is, on the contrary more valuables hair color shallow consequential effects of the poor, white hair as a result of Hair follicle-free treatment of melanoma and therefore null and void.The vein in the leg, telangiectasia, hemangioma is the same reason.

 C.The effect of hair removal connect with the hair growth cycle

Hair growth is divided into three periods: growth, recessive, quiescent period. The different parts have different hair growth cycle. Recessive of the hair quiescent has no significant role in hair growth, and so only in order to play a role. Therefore, laser hair removal takes effect only after repeated obvious.

In the treatment, hair growth in the proportion of the smaller, the number of treatment has to be more. the other hand, growth in the proportion of more treatment, the better. If the scalp, beard, the upper lip hair growth in the proportion is 85%, 70%, 65%. And Ye Mao, bikini, is only 30% growth. In the chest, arms, legs hair growth in the proportion of smaller, representing only 20 per cent. This shows that the effects of good or bad hair, and hair growth cycle and the number of treatment and treatment related to the frequency.

Accessary

Testing

Compare

About us

Guarantee:

1.Jiatailonghe supply you 12 month warranty.
2.Jiatailonghe supply you life time maintenance, cause of our modular design, you do not need to send back the total machine for repair, we could send you the new replacement parts and guide you how to change on your side.
3.Jiatailonghe supply you on line training and training certificate.

Service:OEM&ODM service

1.Jiatailonghe could mark your logo on every one of your machine ordered from us for free.
2.Jiatailonghe could design and produce new frames as your requirements.
3.Jiatailonghe could make your own language for the display.

 Product Pictures

Packing & Shipping

Packing details:There’re different packages of our beauty machines:carton box,aluminium alloy and wooden box. No matter which package,there’s cood foam inside of the box to protect the machine during the shipment.So there’s no worry of any damages of the machine.

Shipping: DHL,UPS,TNT,Fedex etc express courier door to door service and by air cargo to some airport of your country. Delivery within 5-7 working days after payment.
