Model XFFM115-284 colored steel tile forming machine consists of the following : uncoiler and its base, coil sheet guiding equipment, film covered device, roll forming system, pressing equipment, post-cutting equipment, hydraulic station, controlling system, supporter table
Working Flow
Decoiling the Sheet→Sheet Guiding→Film Covering→Roll Forming→Measure Lengh → Cutting the Panel→Panels to the Supporter.
Technical Parameters
Material Spec : Colored and galvanized steel sheet at yield stress 33KSI
Thickness of Coil Sheet : 0.5 --0.6 mm
Coil Width : 1000mm
Working Speed : 2.0 3.0 m/min. (step distance at 380mm)
Power Requirement : Main motor power: 7.5kw
Hydraulic Station Power : 5.5Kw
Passive Uncoiler : Max. Capacity: 5000kgs
Quantity of Stands : About 15groups
Controlling System : PLC
Type of Cutting : Roll-formed and length-set cutting
Machine Dimension : About 18500×1500×1400mm
Total Weight : About 9500kg
Voltage : 380V 3 phase 60Hz or to the buyer's requirement
Machine Features
1. Precise forming.
2. High-solid forming stand guarantees the good and uniform quality of final products
3. The operation automatically minimizes the tolerance of cutting length.
Products Feature
1. A stylish and attractive design,giving the apperance of a traditional roof tile.
2. Resistant to frost,heat,hail and gales : 100% waterproof, thanks to the lateral run-off channel on each sheet for several models.
3. The raw material can be in different color, elegant and noble looking. It is widely used as the garden like factory, hotel, exhibition, villa, civil construction etc.
