Induction Heating Vacuum Coating Metallizing Machine

Inducting heatingwinding metallizing machine(crucible)

Vacuum chamber:rectangle or round chamber type

 Application: gold  or silver wire coating

 Performance: faster, higher ,efficient, muchstable

 Advantage: better uniformity, no sputtering,no pin hole, better fastness of coating          film layer.

Control system:SIEMENS structure, PLCcontrol, higher accuracy AC variable frequency consistenttension winding system

Vacuum system: equipbig power pump group and Polycold, suitable for any environment.

Induction heating type evaporating source is applied to coat Al film with winding vacuum metallizing machine. put the crucible of Al ingot into the central of wire coil(not touch),connect high frequency inside the wire coil, make Al ingot produce current and heat it temperature until evaporating. induction coil is made of copper pipe and filled with cooling water. in order to make film layer much uniformity, each power of crucible coil could be controlled separately ,this equipment its evaporating rate is 10 times bigger than evaporating boat.

evaporating source：high frequency induction heating, graphite crucible induction heating, avoid traditional thickness, make sure least pin hole, winding speed up to 8-11m/s, totally meet market requirement。

—Highquality core parts:—1，SIEMENSmotor—2,  GERMANY Leybold pump—3，ImportedSKF bearing—4，Highquality polycold system—5，Main andsub roller cooling system
