Cotton Direct Digital Fabric Printing Machine Roll To Roll Printing 1500 Kilos
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Custom Fabric Printing Inkjet Roll Printer 5 Pl Drop One Year Guarantee
-
Digital Cotton Fabric Printing Machine Positive Pressure / Wiper 4.2 Pl Droplet
-
Digital Textile Printing Machine Ink Available Knit Digital Printer For Fabric
-
4 - 8 Kyocera Digital Textile Printer Ricoh Head 260 m2 / h Reactive Inks
-
High Speed Belt Type Digital Textile Printing Equipment With Kyocera Head
-
Ricoh Head Digital Textile Printing Machine Automatic Rolling For Bedding Sheets
Product Details
| Brand Name | Tongling | Place of Origin | China | |
| Model Number | TLDP-R1800-8 |
Product Description
Certification:ISO
Cotton Direct Digital Fabric Printing Machine Roll To Roll Printing 1500 Kilos
Cotton direct digital fabric printing machine 1.8m roll to roll printing
High quality digital printing
High speed print output
production model:100 sqm/hour high quality model :80sqm/hour
A. Main specifications:
| Product mode | TLDP-R1800-8 | |
| Print head | 8 Ricoh print head | |
| Fabric conveyance mode | Adhesive belt with cleaning and heating systerm | |
| Maximum printing width | 1800mm | |
| Maximum medium width | 1830mm | |
| Maximum printing resolution | 1200*1200DPI | |
| 2 pass 600x1200dpi | 80-100m2/hour( real printing speed) | |
| 3 pass 1200x1200 dpi | 50-70m2/hour( high quality printing) | |
| Print software | Neostampa/Texprint (origin) | |
| Ink supply system | Peristaltic pump supply,degassing NEG pressure system | |
| Ink Type | reactive , disperse or acid ink,pigment | |
| Ink color | Cyan,Magenta,Yellow,Black,Orange,Red,Blue, Gray | |
| Dryer unit | Aluminum foil heater,infrared heater and hot fan heater | |
| Medium output mode | Automatic winding | |
| Maximum medium length | No limited | |
| Print head height | Height adjustable(0～30mm) to adapt medium of different thickness | |
| Power voltage | 380V,3-phase-4-wire+G(with independent reliable effective earth wire) | |
| Power frequency | 50HZ/60HZ ±1HZ | |
| Power consumption | Printer 10kw,dryer 20kw | |
| size | 3200*1900*1600mm (l w h) | |
B. Pigment processing:
pre-post processing---digital printing--high temperature heating
No washing ,very environmental.
C. Description:
1) Printing head:Gen-5
2) Suitable for multiple fabrics:
3) Main feature:
7 pl nozzle is used to support you with high speed printing and higher resolution
Belt-transporting system,integrated fabric feeding & take-up system,fabric spreading , fabric entry unit.Infrared heating installation:dry quickly the fabric after printing,without belt residue and cross colorAutomatic belt clean & dry installation:always keep the belt for drying in order to support print continuouslyMaterial Automatic height testing function:The machine can test the material height automatically.
4) Warrantee:
Gurantee:One year ,including install,testing and training in your country.
D. Applications:
