Quick Interchangeable CZ Purlin Cold Roll Forming Machine 1.0 - 3.0 mm Thickness

FOB Price

USD $42000 - $42000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TECHWELL		Place of Origin	China
Model Number	TW-GTM

Material: G.i Coil or Carbon steel
Material Thickness:1.0-3.0mm
Landscape orientation adjustment range of Hole distance : 45-500mm
Length of purlin: >3m
Forming Stations: about 16 Main rollers
Leveling Stations: 7
Feeding Stations: 2
Main Power: 20KW
Machine Diameter: about 12000mm(L)x2300mm(W)x1600mm(H) ( including main motor )
Weight of machine: about 18.5 Ton
One machine can produce differenct C/Z Purlins throught simple manual stepless adjustment, when to produce different profiles, no need to change the forming rollers. In the process, machine adopt automactic control model, it can auto punch, cut, forming based on inputting length of purlin, portrait hole distance, quantity, etc datas.
C/Z purlin roll former make up of decoiler, feeding, leveling, 2 sets hydraulic punching device, hydraulic cutting, speediness interchangeable forming machine, PLC control system, hydraulic stations, runout tables.
