Help CenterNGV Natural Gas CNG TANK , High Impact Resistant 250 Bar 3600PSI CNG Steel Cylinder
Related Products
-
Type 2 Natural Gas Cylinder With Fiberglass Wrapped ISO11439 Standard OD 420mmNegotiableMOQ: 1 Piece -
Light Weight NGV Gas Tank for Compressed Gas Vehicles Corrosion ResistantNegotiableMOQ: 1 Set
-
OD 279 - 356 MM NGV Gas Tank With 250 Bar Working Pressure 30L - 150L Capacity ISO9809NegotiableMOQ: 1 Piece
-
Type 2 CNG Carbon Fiber NGV Gas Tank for Natural Gas Vehicles Fuel Storage OD 14\"NegotiableMOQ: 1 Set
-
3600psi OD 11\" NGV Gas Tank for Compressed Natural Gas VehicleDOT-FMVSS-304NegotiableMOQ: 1 Piece
Certification:ISO11439:2000
ISO11439 CERTIFIED 150L & 200L 3600PSI NGV GAS TANK TYPE 1 CNG CRMO STEEL CYLINDER
FEATURES:
Low cost, the most economical CNG storage system
Extremely high storage capacity
Made of seamless steel tube, strong and safe
Resistant to high impact, sunshine, bad weather
Hundreds of different sizes and wide range of thread type
Vehicle OEM industry management system ISO / TS16949 certified
Inner shell coated with rust-resistant paint
20 years service life
Advanced plastic powder spray coating technolog
OUR OEM CUSTOMERS:
Bus OEMs:
Valued supplier of Kinglong, GoldenDragon, Youyi, Howo, Youngman, Hyundai,Sunlong.
Truck OEMs:
Valued supplier of Shacman, Dongfeng, Nanjun, Sinotruck, Hino (Thailand).
Commercial Car OEMs:
Valued supplier of Toyota (Thailand), Ford (USA), Proton (Malaysia).
HOW TO KEEP PRODUCT SAFETY:
A. Shaping Technology (Cylinder Neck and Bottom Spinning)
Our spinning technique prevents all defects which may cause explosion, such as wrinkles,
indentations, cracks, inclusions, and the thickness shortage at the bottom or arc part of the cylinder.
B. Heat Treatment Technology
We developed the strictest requirement on metal ingredients and ratio, to ensure our cylinder can keep
a perfect balance between tensile strength and yield strength, and have uniform shell thickness and
light weight, to prevents hazard cracks, poor metal properties due to poor heat treatment.
C. Raw Material Control
Our steel tube supplier is the best and most famous special steel manufacturer in China.
The steel tubes are custom-made by completely following our own special requirement on metal
ingredients and prescription ratio, which achieve successful and complete transformation of metal,
and significantly improve the mechanical properties of the cylinders
SPECIFICATIONS:
| Model No. |
O.D. inch) |
Volume (L) |
Length W/O Valve (mm / inch) |
Weight (kg / lbs) |
Other Spec. |
| CNP25-145-356A | 356 / 14\" | 145 | 1810 / 71.3 | 168 / 370 | 1. Material: 34CrMo4 steel 2. Design Wall Thickness: 9.6mm for 356mm series 11mm for 406mm series 3. Design Wall Thickness: 4. Working Pressure: 250 bar / 3600psi 5. Test Pressure: 375 bar 6. Burst Test Pressure: 562.5bar 7. Lifetime: 15 years 8. Thread: 3/4 NGT, W28.8, 1.125-12UNF |
| CNP25-200-406A | 406 / 16\" | 200 | 1930 / 76.0 | 240 / 530 |
