Feature of Uhmw-pepipe
1. High impactresistance
Ultra-highmolecular weight polyethylene impact resistance and shock absorption can beamong the top of the plastic, whether strong impact force, or internal pressurefluctuations are difficult to make its cracking.The impact strength is 10 timesof nylon 66, 20 times of polyvinyl chloride (PVC), 4times ofpolyethylene.Especially in the low temperature environment, its impact strengthachieve to higher values.The flexibility of Ultra-high molecular weightpolyethylene provides the guarantee of safe and reliable toconveying system.
2. High wear resistance
In manypipe material, the minimum friction coefficient of ultra-high molecular weightpolyethylene and its has a long chain,make the wear resistance of UHMW-PE pipe during transportation of slurryis 4-7 times higher than steel pipe andstainless steel tube, about 10 times higher than PVC pipe and PE pipe, greatlyimprove the service life of the pipeline.
3. The corrosionresistance
Based onUHMW-PE is a saturated molecular structure, so it has high chemicalstability.In a certain temperature and the concentration range can resist allkinds of high corrosive medium (acid, alkali, salt )and organic solvents.
4. Do not knot dirt
The self-lubrication ,adhesion,minimalfriction coefficient of UHMW-PE.And pipe wall has corrosion resistance, wearresistance, not knot dirt by special process.So the flow resistance is small,can be keep flow velocity and flow rate for a long time.The diameter reduced by15.4% than steel pipe.
5. Weather resistanceand aging resistance
The blackmodified UHMW-PE pipe has good weather resistance and aging resistance.On theone hand,the unsaturated chain of themolecular chain rarely and largemolecular weight of the pipe;On the other hand, specially crafted improvermaking the UHMW-PE pipeline’s servicelife greatly more than the ordinary polyethylene pipes.Using about 60 years,UHMW-PE pipeline can remain more than 70% of the mechanical properties.
6. Wide optimumtemperature
Can be work from -269 ℃ to 80 ℃ for along time.
7. Fire resistance
Used for fireprotection in special industry, join the flame retardant and use specialprocessing craft to overcome the flammability of UHMW-PE itself.
8. Light weight, easyto install
This product has goodtoughness.It Can adapt to various geological conditions, can be directly bentlaid.The flange connection, without spacer block, fast and easy to connect.
Application
Power system: fly ashemissions of coal-fired power plants, chemical water cycle system, sulfurremoval system.
Coal industry:transfer of coal powder, coal-water slurry, supply and exhaust air, drainagesystem, the desulfurization system of the mine.
Chemical industry:conveying the strong acid,strong alkali and other corrosive medium ,saltchemical pulp, salt, crude salt brine.
Oil: crude oiltransportation, natural gas gathering, water injection.
Metallurgicalindustry:transportation of coke powder, mineral powder, pulp and oil refiningslag.
Mining industry:slurry pipeline, the coal mine high pressure water supply, gas supply line.
Dredging project:theengineering of transporting sediment dredging for river, lake, port, wharf.
Ocean engineering,transporting the seawater and fresh water in the desalination process.
Municipalengineering, transportation of sewage treatment, water supply and the coal gasand natural gas.
