Industrial Gantry CNC Plasma Oxy Fuel Cutting Machines 2500 * 6000mm Cutting Size
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
- State-of-art Metal Wire Weaving Machines from LANYING
- Advanced CNC Metal Wire Mesh Weaving Machines from CHINA LANYING
- Plastic leno mesh bag circular loom
- Plastic leno bag circular loom
- Vamatex Leonardo rapier loom-220cm Year 2000 used rapier loom Staubli 2670 dobby with 16 shafts location in China
- Cotton Fabric Weaving machines Air Jet loom Textile Machine
Product Details
Brand Name: | Yahong | Place of Origin: | China | Model Number: | YH2560 |
Product Description
Certification:CE / ISO
Industrial Gantry CNC Plasma Oxy Fuel Cutting Machines 2500 * 6000mm Cutting Size
Industrial Machinery CNC Gantry Oxy Cutting Machine With CNC Control System
Description:
The gantry CNC plasma and flame cutting machine is specially designed for metal plate cutting,it is characterized of high automation and efficiency,easy operation and long service time.This CNC plasma and flame cutting machine is gantry structure with double-driven system, working size can be customized upon requirement.
Competitive Advantage:
1. Steel hollow beam design ensures good heat dissipation without deformation.
2. The gear-rack driving motions without engagement gap ensure the machine running smooth at high speed.
3. Fully functionalized CNC system and optocoupler device enhance the super anti-jamming capability of the plasma system.
4. Multiple cutting torches can be configured.
5. Both flame and plasma torches are optional to meet the needs of cutting different materials in a range of thickness.
Applications:
This machine can cut mild steel with flame cutting, and cut high carbon steel, stainless steel,aluminum, copper and other nonferrous metal with Plasma cutting; can configurate as you required.,thus it is widely applied in industries such as machinery, automobile, shipbuilding, petro-chemical, war industry, metallurgy, aerospace, boiler and pressure vessel, locomotive etc
Technical Parameters for Light Gantry CNC Cutting Machine:
1 | Cutting shape | Steel plate with any plane shapes fromed by straight lines and arcs |
2 | LCD Display Dimension | 7.0 Inches |
3 | Effective Cutting Size | 2500*6000mm |
4 | Railway Size | 3000*7000mm |
5 | Plasma Cutting Thickness | 0.5--20mm ( Depends on plasma power source capacity) |
6 | Flame Cutting Thickness | 5--200mm |
7 | Lifting body | 1 lifting body standard |
8 | Cutting Speed | 0-8000mm per minute |
9 | Height Control | Electric Height Control+Arc Voltage Height Control(THC) |
10 | Drive Mode | Bilateral drive |
11 | Cutting Mode | flame and plasma |
12 | Ignition device | Auto ignition device |
13 | File transmission | USB transmission |
14 | Gas Pressure | Max. 0.1Mpa |
15 | Oxygen Pressure | Max.0.7Mpa |
16 | Cutting Gas |
Flame: Oxygen+ Acetylene/ Propane/ Coal gas Plasma :air |
17 | Software | FastCAM Standard (support Auto CAD/ Solidworks/ CAXA/ Types etc.) |
18 | Cutting accuracy | ±0.5mm |
19 | Power Supply Voltage/Frequency | 220V 50HZ / 60HZ |
20 | Rated Power Supply | 1500W |
21 | Working Temperature | -10℃-60℃, Relative Humidity, 0-95%. |
FAQ:
1. Are you factory or foreign trade company?
We are industry and trade integration.
2. What shall we do if don't know how to operate your machine after bought from you?
We have detailed installation and operating instructions attached, also comes with video, it is very simple. We have telephone and email support at 24 hours a day.
3. What's the quality of your products?
Parts of our products come with best quality, the machine after the installation completed, will be after 48 hours of aging. Also our products passed CE certification, exported to lots countries around the world, such as Russia, Iraq, Belgium, Kazakhstan, Korea, etc. You can rest assured with the quality absolutely.
Light Gantry CNC Cutting Machine:
