25bar 20HP High Pressure Air Compressors

25bar 20HP High Pressure Air Compressors For Blowing Machine

Quick Detail:

Capacity:1.3m3/min 46cfm

Working pressure:25bar  362psi

Motor power:20hp/15kw

Cylinder liner:¢120*2  ¢65*1

AIR TANK:350L

Weight:600kg

Size:1714*715*1318

Description

This series air compressor widely used in pneumatic lock , pneumatic tool , tire inflation , blowing precess, spray paint, sand blasting and fluidic element.

1.High reliability,performance stable

 2.Low exhaust temperature

 3.Small vibration ,low noise

 4.Low fuel consumption

Advantages:

1.  Strongly power-driven and big airend with design, the air compressor owns bigger and heavier main parts than other products in the same trade with better selection and sufficient using of materials especially with main fittings, In addition ,it is more suitable to be applied in the continuous operation under heavy load for long working time ( 24 time) with reliability and longer lifespan.

2.  Special designed is made in heat emission and air flow, which leads to low air-output temperature and low possibility of carbon deposit.

3.  The piston ring imported from Japan is introduce in designing pistol ring , which is durable and sealable .

4.  Crankshaft undergoes high-frequency hardening , which enables it especially abrasion-proof.

Piston air compressor

1. Piston air compressor2. Powerful cast iron pump3. Big horse power for using4. Suitable for use in factories

2. Belt Driven Piston Portable Air Compressor, Powerful Cast Iron Pump, Competitive and Reasonable Price

3. Suitable for Use in Factories, Automatic Systems Auto Service, Finishing and any Works Requiring Compressed Air

4. 100% Tested and Qualified before Packing

 Our Ability

 1. roduce all kinds of high-medium and low pressure air compressor,compressor pump,screw compressor and oil less compressor.CE,GS

2. Portable design, belt type air compressor

3. We can supply kinds of high-medium and low pressure air compressors, compressor pumps,screw compressors and oil less compressors,etc.

4. From 1HP to 20HP available;

air capacity is from 80-3000Lt./min

Air pressure:7bar,8bar,10bar,12bar

Tank from 6Lt. to 1000Lt.

FEATURE OF PRODUCTS

1. Oil-Lubricated air compressor, Italian type air compressor with aluminium head;portable design,easy transporting,fine function with air pressure adjuster,safety device when pressure is over set level;automatic switch;pump head heat-proof cover

ACCESSORIES/SPARE PARTS:

1) User manual

2)  Air filter

3)  Only for oil compressor: Oil plug /Oil bottle

4) Remark of importance: we provide 2 methods for shipping oil air compressor:

5) One is by transporting plug instead of oil plug when air compressor is shipped with oil in crankcase----The advantage is to prevent a possible damage to machine when new users running machine without oil; The caution for this way is user should insert oil plug instead of the transporting plug when first running; and porter should take care of the machine is usually upward, or oil-leakage would possibly taken place

6) Other is by oil bottle, it can prevent any oil leakage when shipping,but user should put oil before running machine, or it will hurt the piston and even burn the motor.

THE WAY OF PACKING

Inner packing: PVC plastic bag with breath hole outside the machine,then foam-block protected

Outside packing:Carton box/or Wooden case
