Home > Products > Rental LED Display > High Brightness Slim Rental Indoor Full Color Led Screen Pixel Pitch 5.68mm
High Brightness Slim Rental Indoor Full Color Led Screen Pixel Pitch 5.68mm
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Custom P5.95 SMD 3528 Rental LED Display Billboard for Concert / Events
-
Pixel Pitch 10mm IP65 Large Outdoor Led Display Screens For Advertising
-
Waterproof P10mm LED Advertising Display Video Wall Screen 960mm X 960mm
-
Energy Saving P10 SMD LED Advertising Display Outdoor Led Screen Panels
-
P16 Outdoor LED Advertising Display With High Definition , Led Display Panel
-
Waterproof Custom Outdoor SMD LED Display Led Screen Pixel Pitch 10MM V120 / H120
Product Details
| Brand Name | LIGHTIN | Place of Origin | China | |
| Model Number | LTI-P5.68-02 |
Product Description
Certification:CCC / TUV-CE / ETL, etc
High Brightness Slim Rental Indoor Full Color Led Screen Pixel Pitch 5.68mm
1.Standard size cabinet design can meet different installation methods.
2.Noiseless and stable,high quality heat conducting silicone and die-casting aluminum structure.
3.140 degree view angle,screen has wider area for different rental requirement,flatness between cabinet units,0.2mm.
4.Real and natural color ,leading calibration technology is applied with advenced color reproduction function to offer a real natural that is completely complied with human eyes visual habit.
Techinical Specification
| Item | Specification | |
| Pixel | Physical pixel pitch: 5.68 mm | |
| Pixel configuration: 1R1PG1PB | ||
| Module | Module resolution: 44 x 44pixel | Module size: 250 x 250mm |
| Cabinet | Cabinet resolution:88x176pixel | Cabinet size:500 x 1000 x90mm |
| Cabinet :15488pixels/cabinet | Module Qty:8pcs=2(W)x4(H) | |
| Material: Aluminum | Weight: 14Kg | |
| Average power: 150W | Max power consumption: 300W | |
|
Electricity parameter |
Brightness: 900 - 1200 nits | |
| Brightness adjusted: 100 grade by software, or by Auto-optic induced | ||
| Color processing: 16bit | ||
| Display color: 280 trillion | ||
| Color temperature(k): 5000 — 9500 (choice by user) | ||
| Physical density: 30976 pixels/sqm | ||
| Whole display flatness: ≤ 1mm juncture | ||
| Best view distance: ≥ 5m | ||
| Best view angle: Horizontal ±80°, Vertical ±80° | ||
|
Storage temperature: -35℃ ~ +85℃ Working temperature: -20℃ ~ +50℃ |
||
| Driving method: Constant driving current | ||
| Refresh frequency: ≥ 300Hz | ||
| Frame rate: ≥ 60Hz | ||
| Humidity(RH): ≤ 90~95% | ||
| Protection grade: IP64 | ||
| Working Voltage: DC 5V | ||
| Power supply: AC 110 / 220V, 50/60Hz | ||
| Average power consumption:300w/sqm | ||
| Max power consumption: 600w/sqm | ||
| MTBF: 10, 000 hours | ||
| Screen lifetime: 100, 000 hours | ||
|
Control system |
Signal interface: DVI | |
| Communication distance: Internet cable: ≤120m Fiber cable: 1000m | ||
| Signal transfer mode: Pixels to pixels display synchronized | ||
Features
1. Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.
2. Thin cabinet:Â the thickness is only 6.5 CM, the space of the screen is small , and the entire screen will be more beautiful.
3. Flat screen:Â smooth surface error is under 0.2cm, it can remove the mosaic phenomenon .effectively. The effect of the display will be more clear and exquisite.
4. Quick dismounting:Â adopt fast locking structure connected, firm, quick, beautiful.
5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.
Advantages
1. For rental use
2. Fast installaion
3. Fast dismantle
4. Light weight
5. Quite slim 75mm
6. Easy build 4:3 or 16:9 ratio
Common Specification of Rental Screen
