ZLP500 Construction Platform / TemporaryAccessPlatforms For Lifting People

ZLP500 Platform Is For Temporary Applications For Lifting People

The model perfectly suited to lightweight applications such as painting and decorating, refurbishing, jointing and repairs, windows cleaning etc.
The complete system consists of the working platform equipped with two electric LTD hoists and the support wheels, suspended by means of steel wire ropes from a suspension structure.

1) Rated Load: 500kg
2) Lifting Speed: 9m/min
3) Voltage-3Phase: 380V/ (415V/220V)
4) Frequency: 50Hz/60Hz
5) Power: 1.1kw×2
6) Hoist: LTD5.0
7) Safety Lock: LSF308
8) Dia. of Wire Rope: 4×31SW8.3mm
9) Platform Size: (2.5×2)×0.76×1.45m
10) Weight of Suspension Jibs: 340kg
11) Weight of Lifting Part: Aluminum290kg/Steel 410kg
12) Counter Weight: 800kg
13) 20\' GP Qty of Package: 12

The different variants are to be distinguished by their suspension principles. Three different stirrups allow to choose the platform the best to your requirements (type of work, type of building, maximum loads, number of persons).

End stirrup:
Fitted at the ends of the platform.
Advantages:
The most economical and lightweight version, although showing extraordinary performances.

\"Frame\" stirrup:
Slipped over the platform like a \"frame\".

Advantages:
The ends of the platform and therefor the building corners are clear and can be easily accessed, exchangeable with the upper part of the end stirrup.

\"L\" stirrup:
Placed at the rear of the platform behind the workers.

Advantages:
The working surface is completely clear and the whole façade can be easily accessed.
