Trapezoidal Z Purlin / Roofing Sheet Roll Forming Machine 4kw Automatic Cutter

Master International Trade Co.,ltd

US$ 8000 - 15000/ MOQ: 1 Set

Key Specifications

Brand Name:

MST

Place of Origin:

China

Model Number:

MST29-200-1000

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name MST

Place of Origin China

Model Number MST29-200-1000

Delivery Time:25working days
Certification:CE/SGS/ISO9001

Trapezoidal Z Purlin / Roofing Sheet Roll Forming Machine 4kw Automatic Cutter

Competitive Advantage:

1. save space

2. easy installation

3. perfect service

4. excellent quality

5. Operate easily

Description:

Trapezoidal roofing is the most popular model of roofing,its widely used in roofing and wall of the workshop.

There is two cylindas on the cutting head of this machine,the hydraulic oil is running into the cylinda,control the cutter easily.

Specifications

NO.	ITEM	PARAMETER	NOTE
1.	Suitable material	Type	Pre-painted sheet, Galvanized sheet
Width(mm)	1000mm
Thickness(mm)	0.3-0.8mm
Yield stress(mm)	G220-G300
2.	Product specifications	Detail as the attached file
Length	Any length
3.	Power requirement	Type	380v/3ph/50hz	Motor brand shanghai Lichao
Main Motor power	4kw
Cutter power	4kw
4.	Forming speed(m/min)	10-15m/min	Not include the time of cutting
5.	Manual Decoiler (Optional)	Type	Manual
Max capacity	5t
Suitable coil OD(MM)	1000
Suitable coil ID(MM)	508
6.	Forming stand	13	Depend on actual design
7.	Thickness of structure	16mm
8.	Forming shaft diameter(mm)	70 solid
9.	Type of cutting	Roll formed and length-set cutting
10.	Control system	Panasonic PLC and inverter
11.	Install dimension(depend on the final design)	6.2m×1.5m×1m	Without panel length
12.	Total weight (Approx)	3.5T	Depend on final design
