Roof Panel Roll Forming Machine With 11 Stations 6211 Bearings Rack 5.5kW Main Motor

Description:

This equipment is a specialized machine set for the roof cold roll forming machine. It is designed and produced according to the requirements of our customers. It is belong to non-standard product.

Applications:

It used for building trades.

Specifications:

1. Material of pressure plate: steel,  thickness: 3.0-6.0mm,  unfolded width about: 1250mm

2. Forming speed: 0-10m/min

3. Forming station: 24

4. Material of roll: 45# high quality steel hard chrome plating

5. Material of principal axis: 45# high quality round steel,  Diameter: φ80

6. Material of chain wheel: 45#,  18 teeth,  16A chain

7. Rack: 350X175 H-beam welding,  panel-type structure,  and 6211 high-quality bearings

8. Main motor power: 5.5KW,  cycloid pin gear speed reducer,  frequency conversion velocity modulation

9. Installation dimension about: (L*W*H): 7.5*1.7*1.4m

10. Use computer to control the length of the product,  hydraulic cutter

11. Material of blade: Cr12,  quenching treatment

12. Hydraulic station power: 55KW

Competitive Advantage:

1.Automatic roll forming machine

2.High quality
3.Factory direct price
4.Design by COPRA@ software from Germany

5.On time delivery

6.Good service
