P10mm Mounted Curved LED Screen Full Color With Bigger Viewing Angle

P10mm Mounted Curved LED Screen Full Color With Bigger Viewing Angle thumbnail-1
P10mm Mounted Curved LED Screen Full Color With Bigger Viewing Angle photo-1
US$ 4 - 5 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
NFCase
Place of Origin:
China
Model Number:
AIA-1
Contact Supplier Request Quote Chat Now
Shenzhen Eastar Electronic Co., Ltd,
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NFCase
Place of Origin China
Model Number AIA-1
Delivery Time:3-5 days
Certification:CE,FCC,MSDS


P10mm Mounted Curved LED Screen Full Color With Bigger Viewing Angle

Feature:

SMD3535 for outdoor usage, high brightness with bigger viewing angle;

IP65 waterproof, front and rear side;

Controlling box is replaceable, press the side button to take it out and insert a new one quickly;

Aluminum case to ensure fast heat elimination, no fans and no noise;

Simple but unique cabinet\'s design, light & thin; side lock system with quick and seamless installation.


Specification:

Model: RK53S RK6S RK8S RK10S RK10S(DIP)
Pixel Pitch (mm): 5.33 6.67 8 10 10
Physical Density (dot/m2): 35,156 22,500 15,625 10,000 10,000
LED Configuration: 1R1G1B 1R1G1B 1R1G1B 1R1G1B 1R1G1B
LED Type: SMD3030 SMD3535 SMD3535 SMD3535 DIP346
Module Size (mm x mm): 320*320 320*320 320*320 320*320 320*320
Module Resolution (PX x PX): 60*60 48*48 40*40 32*32 32*32
Module Power Consumption (W): 70 70 70 70 70
Drive Mode: Constant Current Drive Constant Current Drive Constant Current Drive Constant Current Drive Constant Current Drive
Horizontal Viewing Angle (Deg): 140 140 140 140 140
Vertical Viewing Angle (Deg): 140 140 140 140 140
Brightness (cd/m2): 4,500 4,500 4,500 5,300 8,000
Grey Scale: 14 14 14 14 14
Refresh Rate (Hz): ＞960 ＞960 ＞960 ＞960 ＞960
Cabinet Resolution (PX x PX): 120*120 96*96 80*80 64*64 64*64
Cabinet Max Power Consumption (W): 300 300 300 300 300
Cabinet Average Power Consumption (W): 120 120 120 120 120
Cabinet Size (mm x mm): 640*640 640*640 640*640 640*640 640*640
Cabinet Weight (Kg): 18 16.5 17 17 17
Cabinet Thickness (mm): 89 88 88 88 88
Cabinet Material: Aluminum Aluminum Aluminum Aluminum Aluminum
Color (M): >16.7 >16.7 >16.7 >16.7 >16.7
Input Voltage (V): 110-240VAC 110-240VAC 110-240VAC 110-240VAC 110-240VAC
Refresh Frame Frequency (Hz): 50/60 50/60 50/60 50/60 50/60
Protection Level: IP65 IP65 IP65 IP65 IP65
Working Environment: outdoor outdoor outdoor outdoor outdoor
Working Temperature (℃): \"-20°- +40° \"-20°- +40° \"-20°- +40° \"-20°- +40° \"-20°- +40°
Operation humidity (RH): 10%-90% 10%-90% 10%-90% 10%-90% 10%-90%
Certificates: TUV-EMC,CE TUV-EMC,CE TUV-EMC,CE TUV-EMC,CE TUV-EMC,CE





EASTAR Brand Advantage

EASTAR has been studied in LED Industry for nearly 10 years since it was founded ,and it has mature market in Indoor LED Advertising Display ,Outdoor LED Advertising Display ,Stage LED Rental Display, LED Stadium Display, products has been sold around 5 continents over 100 countries and districts, creates many classical cases, ESDLUMEN brand has been spoken highly of by the clie
