Sell ECG electrode (for Children)

Order code: YD43-6

Size: Children

Shape: Teardrop

Backing: PE foam

Conductive gel: Solid gel

Sensor: Ag/AgCl sensor

Dimensions: 43*49mm

Components:

Metal snap, Ag/AgCI sensor, low impedance solid medical conductive gel, white or original color PE foam tape or cloth tape with medical hypoallergenic adhesive, white PE tape indicated brand mark, PET anti-sticking film.

Parameters:

Metal snap: stainless steel stud, thickness 0.6 mm.

Base PE foam: thickness 1.0mm, density for about 60kg/m³

Base cloth: weight for about 60g/m²

Label Dimensions: Diameter 32mm or 20mm-25mm width

PET anti-sticking film: thickness 0.075mm, 55mm width

Characteristics:

The Ag/AgCl sensor element has the best sensitivities and the solid conductive & adhesive hydro-gel has very low impedance and is non-irritating, non-sensitizing and non-cytotoxic to the skin.

Term of validity: Two years

Inner packing: 10pcs/bag, 50pcs/ aluminum foil & paper pouch

Outer packing: 1000pcs/case, Case dimensions: 450 x 250 x 230mm
G.W.: 2.5kg/case N.W.: 2.0kg/case

We designs and manufacture a full line of high quality ECG electrodes and medical sensors. We specialize in producing ECG electrodes in various shapes, sizes and material to meet different needs of our valuable customers. We also offer Private Label Programs or OEM for a wide variety of products.
